Transmitter Solutions DOLKPL1KB Exterior Stand Alone Keypad
SKU
ts-dolkpl1kb
The Transmitter Solutions DOLKPL1KB is a weatherproof, vandal resistant exterior stand alone keypad with 1000 memory capacity on the 1st relay, metal back-lit keys, and an IP-66 (NEMA 4X) all-weather rating.
Overview
The Transmitter Solutions DOLKPL1KB is an exterior stand alone keypad engineered for demanding outdoor environments. Housed in anodized steel with a powder paint coating outer box and plastic inner box, it features a 1/16 inch stainless steel face plate and metal back-lit keys. It supports surface or gooseneck mounting and operates across a wide temperature range.
Key Features
- Vandal Resistant construction
- Weatherproof with IP-66 (NEMA 4X) all-weather rating
- 2 Relays — 1000 memory on 1st relay; 100 memory on 2nd relay
- Metal back-lit keys
- Surface or gooseneck mount options
- 4-8 digit PINs supported
- Latching or momentary pulse output modes
Specifications
- IP Rating: IP-66 (NEMA 4X) All Weather
- Dry Contact: 50mA/24VDC
- Temperature Rating: -40°F to 158°F
- Humidity: 5-95% relative humidity, non-condensing
- Dimensions: 6-1/8" (H) x 4" (W) x 2" (D) inches
- Weight: 2.2 lbs
- Housing: Anodized steel, powder paint coating outer box and plastic inner box
- Face Plate Material: 1/16 inch stainless steel
- Operating Voltage: 12-24VDC, auto adjusting
- Operating Current: 40mA (quiescent) to 100mA (3 relays active)
The Transmitter Solutions DOLKPL1KB delivers reliable exterior access control with robust weatherproof construction and flexible installation options.
