Viking Access Systems F1NX Swing Gate Operator - Operator Only
The Viking Access Systems F1NX is a residential and commercial swing gate operator featuring a V-Flex control board, removable power supply box for low-voltage wiring, and a 1/4" steel chassis rated for gates up to 1,500 lbs. Operator only; accessories sold separately.
Overview
The Viking Access Systems F1NX Swing Gate Operator is engineered for both residential and commercial applications. Its removable power supply box enables low-voltage wiring runs to the operator, eliminating the need to trench high-voltage lines. The V-Flex control board provides an on-board LCD display for diagnostics and operator status monitoring. The 1/4" steel chassis supports gates up to 1,500 lbs, and the unit ships with soft-start/soft-stop operation, a built-in thermostat-controlled heater, and a true battery backup system. Compliant with ETL and UL 325 standards, the F1NX carries a 5-year commercial or 7-year residential warranty.
Key Features
- V-Flex control board with LCD display for diagnostics and status
- Removable power supply box for low-voltage wiring
- 1/4" steel chassis for increased gate handling capacity
- Soft-start / soft-stop operation
- Built-in thermostat-controlled heater
- True battery backup system — 400 continuous cycles; two 4Ah batteries included
- Adaptive motor control
- Built-in loop rack
- Built-in voltmeter
- Lightning strike protection
- Multiple power options including 120VAC, 240VAC, 24VAC/VDC, and solar
- Anti-tailgating feature
- Fail secure and fail-safe modes
- Mechanical manual release
- 120VAC outlet provided
- Adjustable speed control
- UL 325 Class I, II, III, IV compliant
Specifications
- Maximum Gate Capacity: 12 ft at 1,500 lb / 16 ft at 1,000 lb
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Input Voltage: 120VAC – 2.5A or 240VAC – 1.5A
- Alternative Power Source: 24VAC/VDC (60VA) or Solar
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Accessory Power: 24VDC – 750mA
- Power Consumption (Idle): 70mA
- Motor Current (Typical): 4.0A
- Operating Temperature: -20°F (-28°C) to 160°F (71°C)
- Opening Angle: 120°
- Gate Speed: 13–16 sec./90°
- Battery Backup: 400 continuous cycles
- Monitoring Inputs: Two inputs with up to 4 devices per input
The Viking Access Systems F1NX delivers professional-grade swing gate automation with the reliability and compliance required for residential and commercial installations.
What's Included
- (1) F1 Swing Gate Operator
This listing is for the gate operator only. Remotes, receivers, photocells, and other accessories are sold separately.
