Maximum Controls MAX-1700-FS-PRO Fail Safe Slide Gate Operat
The Maximum Controls MAX-1700-FS-PRO is a fail safe, high traffic commercial brushless DC sliding gate operator rated for gates up to 1,700 lbs and 40 ft, operating on 24VDC with battery backup and solar-ready capability.
Maximum Controls MAX-1700-FS-PRO Fail Safe Slide Gate Operator
The MAX-1700-FS-PRO is a robotic DSP-controlled sliding gate operator engineered for high-traffic gated communities, commercial and industrial applications, and public storage facilities. It handles gates up to 1,700 lbs and 40 ft in length, delivers fail safe back-drivable manual operation upon loss of AC power or battery depletion, and is built around the Matrix-III PRO Series control board. Installation must be performed by a professional gate installer — tech support and warranty coverage apply only when installed by industry professionals.
Key Features
- Continuous duty brushless DC motor equivalent to 1¼ HP AC motor
- Direct gear drive — no internal chains, belts, or pulleys
- Heavy duty direct drive gearbox — Size 60, 20:1 gear ratio
- Hall Effect sensing with adaptive DSP control for advanced brushless DC motion control
- Local keyed manual disconnect — allows gate to be pushed back
- Remote keyed manual disconnect — allows gate to be pushed back from outside the property via keypad or any dry contact command
- Dynamic braking system in closed position resists unauthorized push-back attempts
- Audible alarm and relay output triggered on unauthorized entry (push-back) attempt
- Matrix-III board makes the operator solar ready; with Solar Power Pack installed, supports solar and sleep mode operation
- Solar Combiner supports up to 4 Solar Power Packs with 200W solar panels wired as a single-ended 24VDC supply — UL approved expandable feature
- Intelligent ramp-up and ramp-down for smooth operation; selectable short or long ramp-down
- Selectable open timer 0 to 60 seconds with timer-off option
- Independent opening and closing speed control for primary and secondary
- 16 selectable programmable gate speeds
- Programmable virtual OPEN & CLOSE limits (auto-set on total power loss)
- Optional magnetic limit sensors available
- Real-time performance analyzer and event log (OBD Port and Black Box) — 8,000 events including error and failure history
- LCD display reporting past and recent errors
- Low voltage wiring capability for remote power-up up to 500 ft (no battery needed)
- Built-in 12VDC and 24VDC outputs
- Switchable 115/230 voltage selection
- Corrosion protection via gold zinc coating and electrostatic powder coating
- Continuous cycle at extreme temperatures — overheating not possible
- Operational temperature range: -4°F to 165°F (-20°C to +74°C) including battery performance without a heater
- Gold contact input connections and automobile-grade connectors
- Lockable cover with key lock release
- Advanced anti-tailgate feature
- High-traffic intuitive loop management system
- Magnetic lock control relay outputs with selectable delay times
- Tamper-alert relay output triggers on if gate is forced open
- Gate partial open recorder with programmable inputs for high-traffic and emergency vehicle cycles
- Optional Chain Drop Sensor detects unauthorized chain drops when using magnets option
- Fire Department Compliance — gate auto-opens upon loss of AC power or battery depletion
- Gate status outputs for gate monitoring
- 24VDC battery backup with up to 200 full cycles
- Includes 25 ft #40 Nickel Plated Chain & Brackets
- Modular system design for ease of service
- Patent No. US 9,406,207 B2
- 5-Year Limited Manufacturer Warranty
- Additional Entrapment Prevention Devices REQUIRED
Specifications
- Operating Voltage: 24VDC
- Power Source: 115/230VAC switchable or 24VDC Solar
- Gate Capacity: 1,700 lbs / 40 ft maximum gate length
- Gate Speed (Class I & II): ~12 inches per second
- Gate Speed (Class III & IV): Up to 19 inches per second (adjustable via dip switch configuration)
- Motor: Continuous duty brushless DC, equivalent to 1¼ HP AC
- Gearbox: Heavy duty direct drive, Size 60, 20:1 gear ratio
- Dimensions: 14.5" W x 19" D x 25.5" H; 7.5" chain height
- Shipping Weight: 156 lbs
- Operational Temperature: -4°F to 165°F (-20°C to +74°C)
- Event Log: 8,000 events
- Battery Backup Cycles: Up to 200 full cycles
- Chain: 25 ft #40 Nickel Plated with Brackets
- Manufacturer Part Number: MAX-1700-FS-PRO
The Maximum Controls MAX-1700-FS-PRO delivers professional-grade fail safe performance, advanced security, and expandable solar capability for demanding commercial slide gate installations.
