Viking Access Systems G5DLK G5 Swing Gate Operator Dual Kit
The Viking Access Systems G5DLK is a complete dual swing gate operator kit featuring two G5 swing gate operators, an ECU Dual control board, true battery backup, and a full accessory package for professional dual-leaf gate installations.
Overview
The Viking Access Systems G5DLK G5 Swing Gate Operator Dual Kit provides everything needed for a dual-leaf swing gate installation. The kit includes two VA-G5NX G5 Swing Gate Operators paired with a VA-ECUMSNX2 ECU Dual control board, delivering a 100% duty cycle and UL 325 Class I, II, III, and IV compliance. Operating at 24VDC, each motor is powered by either 120VAC at 1.5A or 240VAC at 1.0A and achieves a gate speed of 15–18 seconds per 90° with an opening angle of up to 135°. True battery backup provides 400 continuous cycles during power outages.
Kit Includes
- (2) VA-G5NX — G5 Swing Gate Operator
- (1) VA-ECUMSNX2 — ECU Dual Controller for Kits
- (1) FA-XR2C — 433 MHz Receiver
- (2) FA-XT4RC — 433 MHz RC Transmitter
- (1) FA-XP30-10K — Photocell 10K Resistor
- (2) FA-XP30AC — Photocell Adapter
- (1) DJBK — Junction Box
- (40 ft) VA-CB16 — 6-Conductor Cable, 16 AWG Shielded
Key Features
- Adaptive motor control
- Built-in thermostat-controlled heater
- Built-in voltmeter
- Lightning strike protection
- On-board display
- True battery backup — 400 continuous cycles
- Adjustable speed control
- Anti-tailgating feature
- Fail secure mode and fail-safe mode
- Electronic manual release
- Lockable cover
- Large box option (optional, with 120V outlet)
- Multiple power options and multiple power outage options
- Two monitoring inputs with up to 4 devices per input
- UL 325 compliant
Specifications
- UL 325 Classification: Class I, II, III, IV
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Voltage / Current (each motor): 120VAC – 1.5A or 240VAC – 1.0A
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Alternative Power Source: 24VAC / VDC (60VA) or Solar
- Accessory Power: 24VDC – 750mA
- Power Consumption (Sleep): 28mA
- Motor Current (Typical): 3.0A
- Operating Temperature: -20°F (-28°C) to 160°F (71°C)
- Opening Angle: 135°
- Gate Speed: 15–18 sec./90°
- Battery Backup: 400 Continuous Cycles
The Viking Access Systems G5DLK is a professional-grade dual swing gate kit engineered for reliable, high-performance access control in demanding applications.
