Viking Access Systems G5SLK G5 Swing Gate Operator Single Ki
The Viking Access Systems G5SLK is a single-kit linear actuator swing gate operator featuring a 100% duty cycle, V-Flex control board with diagnostic LCD display, and pre-wired components for fast professional installation.
Overview
The Viking Access Systems G5SLK G5 Swing Gate Operator Single Kit leads the industry in linear actuator swing gate operator performance. Powered by the V-Flex control board — which includes a speed control dial and diagnostic LCD display — this operator delivers 100% duty cycle operation. It is solar efficient and ready for low voltage wiring, offering versatile installation options. The G5SLK is ETL and UL 325 compliant and features a convenient electronic manual release switch. A Photo Beam is required for this operator to function.
Key Features
- V-Flex control board with speed control dial and diagnostic LCD display
- 100% duty cycle operation
- Adaptive motor control
- Electronic manual release
- Built-in thermostat-controlled heater
- Built-in voltmeter
- Lightning strike protection
- Anti-tailgating feature
- Fail secure mode and fail-safe mode
- Multiple power options
- Multiple power outage options
- Lockable cover
- Large box option available
- True battery backup — 400 continuous cycles
- Solar efficient and low voltage wiring ready
- On-board display
- Two monitoring inputs with up to 4 devices per input
- Pre-wired for quick professional installation
Specifications
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Voltage Current Specs: 120VAC – 1.5A or 240VAC – 1.0A (each motor)
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Operating Temperature: -20°F (-28°C) to 160°F (71°C)
- Opening Angle: 135°
- Gate Speed: 15–18 sec./90°
- Battery Backup: 400 Continuous Cycles
- Alternative Power Source: 24VAC/VDC (60VA) or Solar
- Accessory Power: 24VDC – 750mA
- Power Consumption – Sleep: 28mA
- Motor Current (Typical): 3.0A
- UL 325 Classification: Class I, II, III, IV
Kit Includes
- (1) VA-G5NX — G5 Swing Gate Operator
- (1) VA-ECUSNX2 — ECU Single Controller for Kits
- (1) FA-XR2C — 433 MHz Receiver
- (2) FA-XT4RC — 433 MHz RC Transmitter
- (1) FA-XP30-10K — Photocell 10K Resistor
- (2) FA-XP30AC — Photocell Adapter
The Viking Access Systems G5SLK is a professional-grade swing gate operator solution engineered for reliable, high-cycle performance across a wide range of installation environments.
