Linear R4222 Safety Photo Beams
The Linear R4222 is a 12V non-contact photoelectric dual beam detector that uses pulsed infrared through-beam technology to provide entrapment protection for gate operators. When an obstruction is detected, the gate stops and reverses to the fully open position.
Overview
The Linear R4222 Safety Photo Beams deliver reliable, non-contact entrapment protection for gate operators. Using pulsed infrared dual beam and through-beam technology, the system is more reliable than retro-reflective photo beam systems and reduces false detections. When the beams detect a moving object, the gate stops and reverses to the fully open position — and remains open as long as the beam is obstructed. Not compatible with solar powered gate operators.
Key Features
- Pulsed infrared dual beam through-beam technology
- More reliable than retro-reflective photo beam systems
- Range of 30 ft. (9.1 m) between sender and receiver
- Constructed of black PC resin
- LEDs for alignment and troubleshooting
- Universal mounting to any solid surface
- Two-year manufacturer's warranty
- Provides a non-contact means of entrapment protection
Specifications
- Voltage: 12V
- Maximum range: 30 ft. (9.1 m)
- Housing material: Black PC resin
Compatibility
The Linear R4222 is compatible with a wide range of gate operators, including:
- Estate Swing: E-S 1100, E-S 1102, E-S 1600, E-S 1602, E-SC 1600, E-SC 1602, E-SU 2200, E-SU 2202, E-SL 1200, E-SL 1800, E-SL 2000AC
- GTO/PRO: SW2000, SW2002, SW2500, SW2502, SW3000, SW3002, SW4000, SW4002, GPSW100, GPSW102, SL1000, SL1002, SL2000, SL2002, GPSL100, GPSL102, old Pro 1000/1002 & 2000/2002
- Mighty Mule: FM350, FM352, FM500, FM502, old FM700 & FM702
- Apollo: 1500, 1600, 1550, 1650, 3500, 3600, 7000UL, BA-12
- Zareba: G450, G452, G550, G552, G750, G752
- Compatible with many other gate operators — not compatible with solar powered gate operators
The Linear R4222 is a dependable entrapment protection solution for professional gate installations.
