Linear R4500 GTO Wireless Exit Wand
The Linear R4500 is a wireless vehicle sensor exit wand compatible with all gate openers, featuring a Narrow Band Receiver for enhanced reliability and up to 100 ft. range.
Overview
The Linear R4500 GTO Wireless Exit Wand is a magnetometer-based vehicle sensor that detects changes in the Earth's magnetic field as a vehicle passes by, triggering your gate to open. The wireless design eliminates the need for a direct wired connection between the sensing coil and the receiver, reducing the risk of control board damage from power surges. The unit ships with two AA batteries included.
Key Features
- Narrow Band Receiver for improved reliability
- Wireless connection between the magnetometer and receiver
- Transmitter includes a 15 ft. lead wire for mounting away from the driveway edge
- Internal potentiometer board adjusts sensitivity from 3 to 12 ft. radius
- Two-piece construction: sensing coil and electronics for straightforward installation
- Eliminates risk of control board damage caused by power surges through wired exit wands
- (2) AA Batteries included
Specifications
- Range: Up to 100 ft.
- Sensitivity Adjustment: 3 to 12 ft. radius (via internal potentiometer board)
- Transmitter Lead Wire: 15 ft.
- QB ID: R4500
- Also known as: Mighty Mule FM130
Compatibility
The Linear R4500 is compatible with all gate openers.
Note: Exit wands should not be used on properties where the driveway gate is intended to contain pets, children, or livestock, due to the possibility of unintentional openings.
The Linear R4500 delivers wireless convenience and reliable vehicle detection for professional gate installations.
