HARDWARE, MAIN SPRING BRACKET - 3" 4" 5"

Overview

The All-O-Matic 22-345 is the main spring bracket component for California Lift Gate jamb track hardware systems. It is designed for use with 3", 4", and 5" jamb track configurations and works in conjunction with the main pivot angle bracket during gate spring installation.

Key Features

• Compatible with Short Set, Regular Long Set, Jumbo, Heavy, and Heavy Jumbo Long hardware configurations
• Bolts directly to the main pivot angle bracket
• Lower holes on the main spring angle bracket are for lighter gates; upper holes are for heavier gates
• Works with spring adjusting bolt threaded through spring for tension adjustment

Specifications

• Track Size Compatibility: 3", 4", and 5" jamb track
• Bottom of Main Pivot Bracket (Mark C) — Short Set: 40" from top of gate
• Bottom of Main Pivot Bracket (Mark C) — Regular Long Set: 43" from top of gate
• Bottom of Main Pivot Bracket (Mark C) — Jumbo & Heavy: 43" from top of gate
• Bottom of Main Pivot Bracket (Mark C) — Heavy Jumbo Long: 49" from top of gate

Compatibility

Designed for use in All-O-Matic California Lift Gate jamb track hardware systems.

Order the All-O-Matic 22-345 main spring bracket to keep your California Lift Gate installation complete and properly balanced.
