Maximum Controls MAX-RHINO-4000 Heavy Duty Slide Gate Operat
The Maximum Controls MAX-RHINO-4000 is a high-traffic industrial brushless DC slide gate operator rated for gates up to 4,000 lbs, with 24VDC operation and built-in battery backup.
Overview
The Maximum Controls MAX-RHINO-4000 is a heavy-duty industrial slide gate operator engineered for continuous duty cycles in the most demanding commercial environments. Powered by a brushless DC motor equivalent to a 2½ HP AC motor, it operates on 24VDC and supports gates up to 4,000 lbs. The unit is solar ready and features the Matrix-III PRO Series control board. Fail-safe, back-drivable manual operation is available upon loss of AC power or battery depletion. Class III and IV applications only. Installation must be performed by a professional gate installer — tech support and warranty coverage apply only under this condition.
Key Features
- Continuous duty, brushless DC motor equivalent to 2½ HP AC motor
- Fail-safe, back-drivable manual operation upon AC power loss or battery depletion
- Matrix-III PRO Series control board with large LCD display
- On-board diagnostic log records 8,000 past events; displays current and past errors
- Dynamic braking system in closed position resists unauthorized push-back; triggers audible alarm and relay output
- Built-in 24VDC battery backup with (2) Yuasa 12V 7Ah AGM batteries
- Up to 200 full cycles on battery backup
- Emergency jog function allows entry in the event of UL failure
- Independent open and closing speed control, adjustable from 10" to 19" per second
- Programmable virtual limit standard; optional magnetic limit sensors available
- Gate status outputs for gate open/close monitoring
- Direct drive gearbox in oil bath — fewer moving parts, quieter operation
- Advanced lightning strike protection up to 20,000 Volts / 10,000 amps
- Hall Effect sensing
- Operational temperature range: -4°F to 165°F (-20°C to +74°C) including battery performance
- Lockable steel covers to restrict unauthorized program changes
- Patented chain drop can trigger an alarm wirelessly and silently
- Solar combiner supports up to 4 Solar Power Packs with 200W solar panels wired as a single-ended 24VDC supply — UL approved
- Includes 30 ft. #50 nickel plated chain; chain tray compatible
- Motor overcurrent safety shutoff
- Safety monitor device types: normally closed or 10K (most safety inputs in the industry)
- Additional entrapment prevention devices REQUIRED
- UL 325/991 compliant — Class III and IV; CSA approved
- 3-year limited manufacturer warranty on gate operator; 1-year battery warranty
Specifications
- Model: MAX-RHINO-4000
- Brand: Maximum Controls
- Manufacturer Part Number: MAX-RHINO-4000-FS
- Maximum Gate Weight: 4,000 lbs
- Maximum Gate Length: 60 ft.
- Operational Voltage: 24VDC
- AC Power Input: 115V / 230V AC single phase
- Solar Input: 24VDC solar panel compatible
- Open Speed: approximately 10" to 19" per second (adjustable)
- Battery Backup: (2) Yuasa 12V 7Ah AGM batteries
- Backup Cycles: Up to 200 full cycles
- Chain: 30 ft. #50 nickel plated (included)
- Unit Dimensions: 14.5" W x 19 5/8" D x 29" H
- Unit Weight: 225 lbs
- Operational Temperature Range: -4°F to 165°F (-20°C to +74°C)
- Application Class: Class III and IV only
The Maximum Controls MAX-RHINO-4000 delivers the reliability, safety, and industrial-grade performance required for your most demanding commercial access control installations.
