Maximum Controls MEGA2200-HP-PRO Swing Gate Operator
The Maximum Controls MEGA2200-HP-PRO is a continuous duty, brushless 24V DC swing gate operator rated for gates up to 2,500 lbs./15 ft. or 1,800 lbs./20 ft., with direct gear drive and a 5-year limited manufacturer warranty.
Overview
The Maximum Controls MEGA2200-HP-PRO is a high-traffic, heavy-duty commercial brushless DC swing gate operator engineered for demanding access control environments. Its direct gear drive system — with no chains, belts, or pulleys — delivers gate opening speeds of 11-1/2 to 18 seconds based on gate weight and selectable speed control. The unit ships with a 24VDC AGM battery backup system with two 7-Ah batteries, providing over 400 full cycles in the event of a power failure. Installation is backed by a 5-year limited manufacturer warranty, and additional entrapment prevention devices are required. This operator must be installed by a professional gate installer; the warranty is void if installed by anyone other than a qualified professional.
Key Features
- Continuous duty brushless DC motor, equivalent to 1/2 HP AC motor
- Direct gear drive — no chains, belts, or pulleys
- Heavy-duty 900:1 Size 80 gearbox
- 3-1/4" diameter solid steel output shaft with cast iron clamping system
- Intelligent ramp-up and ramp-down gate speed control for smooth operation
- 16 selectable programmable gate speeds
- Matrix-III board: solar ready with built-in advanced solar regulator
- Compatible with Solar Power Packs; up to 4 packs with 200W solar panels via Solar Combiner (UL approved)
- Switchable 115/230V AC input selection
- Adaptive DSP control for advanced brushless DC motion control
- Tunable 16-position safety obstruction sensor, auto-adaptable to gate weight and size
- Dual motor overcurrent safety shut off
- Dynamic magnetic brake system stops gate immediately
- Vehicle hit protection technology protects operator from collision damage
- Robust lightning protection up to 20KVolts and 10KAmps on all inputs and outputs (44 channels), including loop detector input connections
- Real-time performance analyzer and event log (OBD Port and Black Box)
- Low voltage wiring capability for remote power up to 1,000 feet (no battery needed)
- Selectable open timer: 0 to 60 seconds with timer off option
- Operational temperature range: -4°F to 165°F (-20°C to +74°C), including battery performance without a heater
- Built-in current limited 12VDC and 24VDC outputs
- Gold contact input connections and automobile-grade connectors
- Mechanical and electrical manual gate release functions
- Corrosion protection gold zinc coating
- Three modes of selectable battery backup functions
- On-board three-button station
- Pinch arm protection design
- Automatic gate position reset system
- Built-in advanced entrapment protection and alarm output
- Built-in gate-in-motion alarm for industrial applications
- UL 325/991 compliant — Class I, II, III, and IV; CSA approved
Security Features
- High-traffic intuitive loop management system
- Tamper alert relay outputs triggered if gate is forced open
- Audible alarm if gate is tampered with or ERD is triggered
- Gate disable feature — disables all inputs except the fire department input
- Magnetic lock control relay outputs with selectable delay times
- Advanced anti-tailgate features
- Lockable cover with key lock release
- Built-in transaction buffer
- Gate status outputs for gate monitoring
- Gate partial open recorder
- Direct motor control of jog OPEN/CLOSE for manual emergency gate movement
Specifications
- Operational Voltage: 24VDC
- AC Input: Switchable 115/230V AC
- Gate Capacity: 2,500 lbs./15 ft. or 1,800 lbs./20 ft.
- Gate Opening Speed: 11-1/2 to 18 seconds (weight and speed-setting dependent)
- Gearbox: 900:1 Size 80
- Output Shaft: 3-1/4" diameter solid steel
- Dimensions: 16.81" W x 24.5" D x 29.92" H; arm height 26.61"
- Battery Backup: 24VDC with two 7-Ah AGM batteries; 400+ full cycles
- Operational Temperature: -4°F to 165°F (-20°C to +74°C)
- Lightning Protection: Up to 20KVolts / 10KAmps, 44 channels
- Warranty: 5-year limited manufacturer warranty
- Certifications: UL 325/991 Class I, II, III, IV; CSA approved
Compatibility
The MEGA2200-HP-PRO is compatible with existing installations and in most cases can be directly bolted onto concrete pads used by the most common gate operators in the industry. Replaces part number MAX-MEGATRON-2200-PRO.
The Maximum Controls MEGA2200-HP-PRO delivers industrial-grade performance, advanced security, and proven solar-ready technology for high-traffic commercial swing gate installations.
