Transmitter Solutions RECTSNANO433 Hive Nano 433MHz Receiver

Overview

The Transmitter Solutions RECTSNANO433 Hive Nano Receiver is a compact 433MHz standalone receiver designed for reliable access control applications. It features a self-adjusting 12–24 VAC/DC power supply, supports up to 85 memorizable users, and includes an adjustable time hold feature of up to 30 seconds. Backed by a 5-year warranty.

Key Features

• Carrier Frequency: 433MHz
• Range: 500 to 600 ft
• Power Supply: 12/24 VAC/DC self-adjusting
• 1-Channel operation
• Adjustable time hold feature (up to 30 seconds)
• 5-Year Warranty
• Housing Protection: IP2X
• Operating Temperature: -4°F to +158°F

Specifications

• Carrier Frequency: 433MHz
• Local Oscillator Frequency: 6.6128MHz
• Power Supply: 12/24 VAC/DC
• Consumption at 12V: 9mA at rest, 26mA relay activated
• Consumption at 24V: 9mA at rest, 31mA relay activated
• Modulation: AM/ASK
• Number of Memorizable Users: 85
• Number of Relays: 1
• Output Contact Type: C-NO
• Commutable Power: 24VA
• Maximum Relay Voltage: 60V
• Absorption: 95mA
• Housing Protection: IP2X
• Operating Temperature: -4° to +158°F
• Overall Dimensions: 2 x 1.25 x 0.8 inches

Compatible Accessories

• Stingray 433MHz
• Monarch 433MHz
• Luna 433MHz

The Transmitter Solutions RECTSNANO433 delivers dependable single-channel 433MHz receiving performance in a compact, low-power form factor.
