Transmitter Solutions MINI2OUT 433MHz 2-Channel Receiver

Overview

The Transmitter Solutions MINI2OUT HIVE Mini Outdoor Receiver delivers long-range wireless reception up to 1,200 feet on the 433.92 MHz frequency. Featuring a superheterodyne receiver design and rolling code security, it supports up to 85 user codes and offers both momentary and latching relay options. The IP65-rated housing is built for exterior-grade installations, with an interior housing option also available.

Key Features

• Long-range reception up to 1,200 feet
• Push to Learn programming — stores up to 85 remotes
• Exterior-grade IP65 housing; interior housing also available
• Momentary or Latching relay options
• Whip antenna included; coax antenna optional
• Available in low-consumption version for solar applications
• Rolling code security with 64-bit rolling code and up to 2 max code combinations
• Compatible with 12/24 Vac/dc power supply

Specifications

• Receiver Type: Superheterodyne
• Carrier Frequency: 433.92 MHz
• Local Oscillator Frequency: 6.6128 MHz
• Demodulation: AM/ASK
• Local Oscillator: VCO / PLL
• Channel Width: > 25 KHz
• Intermediate Frequency: 10.7 MHz
• Input Sensitivity: -115 dBm
• Local Oscillator Spurious Emissions: < -57 dBm
• Input Load: 50 Ohm
• Power Supply: 12 / 24 Vac/dc
• Consumption (Steady / 12 Vdc, 2 relays excited): 15 mA / 49 mA
• Consumption (Steady / 24 Vdc, 2 relays excited): 19 mA / 55 mA
• Max Applicable Power: 24 VA
• Number of Relays: 2
• Relay Contacts: NO, NO/NC
• Memory Capacity: 85 user codes
• TX Security Code: Rolling code 64
• Operating Temperature: -4° / +158°F
• Housing Protection: IP65
• Weight: 4.5 oz
• Overall Dimensions: 3-1/8 x 3-1/8 x 2 inches

The Transmitter Solutions MINI2OUT is a professional-grade wireless receiver engineered for reliable long-range performance in demanding outdoor installations.
