Transmitter Solutions WIE433 Wiegand Receiver
SKU
ts-wie433
The Transmitter Solutions WIE433 is an indoor 26-bit Wiegand receiver supporting 295MHz, 318MHz, and 433MHz frequencies with Keeloq® Hopping Code and a 5-year warranty.
Overview
The Transmitter Solutions WIE433 (HIVE) is an indoor Wiegand receiver designed to operate across 295MHz, 318MHz, and 433MHz frequencies. It delivers 26-bit Wiegand output and features Keeloq® Hopping Code technology. The unit ships complete with a coax antenna and wiring harness, and is compatible with Linear, Sentex, and Doorking systems.
Key Features
- Supports 295MHz, 318MHz, and 433MHz (433MHz long range)
- Keeloq® Hopping Code
- 5-year warranty
- Includes coax antenna and wiring harness
- Indoor installation
- Mobile credentials available using SynQ
- Compatible with 26-bit devices
Specifications
- Output Type: Wiegand (26-bit)
- Input Power: 12–24 VAC/DC
- Power Consumption: 24mA Max
- Output Current: 250mA
- IP Protection: IP2X
- Dimensions: 4 x 1¾ x 1 in
- Weight: 2.3 oz
- Operating Temperature: -40°F – 158°F
Compatibility
- Compatible with Linear, Sentex, and Doorking systems
- Accessories: Monarch 318MHz, 433MHz, 295MHz
- Accessories: Stingray 318MHz, 433MHz, 295MHz
The Transmitter Solutions WIE433 is a reliable, multi-frequency Wiegand receiver built for professional access control installations.
