Transmitter Solutions HIVE433DIP 433MHz DIP Switch Receiver
SKU
ts-hive433dip
The Transmitter Solutions HIVE433DIP is a 433MHz, 2-channel receiver with 10 DIP switches, operating on 12–24 VAC/DC. Includes a coax antenna and wiring harness.
Overview
The Transmitter Solutions HIVE433DIP is a 433MHz DIP switch receiver designed for reliable 2-channel access control applications. The maroon-colored unit ships complete with a coax antenna and wiring harness, ready for professional installation.
Key Features
- 2-channel receiver operation
- 10 DIP switches for code configuration
- 433MHz frequency
- Includes coax antenna and wiring harness
- Maroon housing
- Wide operating temperature range: -40°F to 158°F
Specifications
- Input Voltage: 12–24 VAC/DC
- Output Load Max: 15A / 125VAC
- Power Consumption: 32mA / 70mA Max
- Applicable Power Max: 25VDC
- Operating Temperature: -40°F – 158°F
- Dimensions: 3"W x 3½"L x 1¼"D
The Transmitter Solutions HIVE433DIP delivers straightforward DIP switch programming in a compact, field-ready package.
