Transmitter Solutions RECTS433SEQ Sequencing Vestibule Recei
The Transmitter Solutions RECTS433SEQ is a 433 MHz sequencing vestibule receiver featuring code-hopping technology, dual-relay output, and adjustable timing modes — ideal for electric door strikes, mag locks, and automation applications.
Overview
The Transmitter Solutions RECTS433SEQ HIVE 433 MHz Sequencing Vestibule Receiver is a versatile receiver designed for use with electric door strikes, mag locks, and other automation needs. It operates on 433 MHz code-hopping technology and supports 12/24 VAC/DC power input, making it adaptable to a range of installation environments.
Key Features
- Time-adjustable delay mode: 0 to 30 seconds
- Pulse mode: momentary or 10-second hold time
- Latching mode
- 433 MHz code-hopping technology
- Operates on 12/24 VAC/DC
- Stores up to 85 transmitter keys
- Compatible with a variety of wall-mounted and handheld transmitters
Specifications
- Operating Frequency: 433 MHz
- Local Oscillator Frequency: 6.6128 MHz
- Intermediate Frequency: 10.7 MHz
- Sensitivity (for good signal): -115 dBm
- Input Impedance: 80 Ohm
- Current Consumption (at rest): 25 mA
- Current Consumption (1 relay excited): 55 mA
- Number of Relays: 2 (1NO, 1NO or NC)
- Commutable Max Power: 24W or 24VA
- Max Codes: 85 transmitter keys
- Operating Temperature: -4 to +158°F
- Dimensions: 4.1 x 1.8 x 1.1 inches
- Weight: 2.3 ounces
- Pulse Time: 0.5 / 10 sec.
- Delay Time: 1–30 sec.
Compatibility
The RECTS433SEQ is compatible with a variety of both wall-mounted and handheld transmitters operating on the 433 MHz frequency.
The Transmitter Solutions RECTS433SEQ delivers reliable sequencing control in a compact, professionally installed receiver.
