Transmitter Solutions WIE318-D Wiegand Receiver
SKU
ts-wie318-d
The Transmitter Solutions WIE318-D is an indoor Wiegand receiver supporting 295 MHz, 318 MHz, and 433 MHz frequencies, compatible with Linear, Sentex, and DoorKing systems.
Overview
The Transmitter Solutions WIE318-D is the HIVE Wiegand Receiver designed for indoor use, operating across 295 MHz, 318 MHz, and 433 MHz frequencies. It features KeeLoq® Hopping Code technology and comes complete with a coax antenna and wiring harness. Compatible with 26-bit devices.
Key Features
- Supports 295 MHz, 318 MHz, and 433 MHz (Long Range)
- KeeLoq® Hopping Code technology
- Includes coax antenna and wiring harness
- 5-year warranty
- Indoor installation
- Compatible with 26-bit devices
- Mobile credentials available using SynQ
Specifications
- Input Power: 12–24 VAC/DC
- Power Consumption: 24mA Max
- Output Current: 250mA
- Output Type: Wiegand
- IP Protection: IP2X
- Dimensions: 4 x 1¾ x 1 in
- Weight: 2.3 oz
- Operating Temperature: -40°F to 158°F
Compatibility
- Compatible with Linear, Sentex, and DoorKing systems
- Works with Monarch transmitters (318 MHz, 433 MHz, 295 MHz)
- Works with Stingray transmitters (318 MHz, 433 MHz, 295 MHz)
The Transmitter Solutions WIE318-D delivers reliable multi-frequency Wiegand reception for professional access control installations.
