Transmitter Solutions WIE318-L Wiegand Receiver
SKU
ts-wie318-l
The Transmitter Solutions WIE318-L is an indoor Wiegand receiver supporting 295MHz, 318MHz, and 433MHz frequencies with KeeLoq® Hopping Code and a 5-year warranty.
Overview
The Transmitter Solutions WIE318-L HIVE Wiegand Receiver is an indoor-rated receiver designed for use with Linear, Sentex, and DoorKing access control systems. It operates across three frequencies — 295MHz, 318MHz, and 433MHz — and ships complete with a coax antenna and wiring harness.
Key Features
- Supports 295MHz, 318MHz, and 433MHz (Long Range)
- KeeLoq® Hopping Code security
- 5-year warranty
- Includes coax antenna and wiring harness
- 12–24 VAC/DC input power
- Indoor installation
- Compatible with 26-bit devices
- Mobile credentials available using SynQ
Specifications
- IP Protection: IP2X
- Input Power: 12–24 VAC/DC
- Power Consumption: 24mA Max
- Output Current: 250mA
- Output Type: Wiegand
- Operating Temperature: -40°F – 158°F
- Dimensions: 4 x 1¾ x 1 in
- Weight: 2.3 oz
Compatibility
- Compatible with Linear, Sentex, and DoorKing systems
- Compatible accessories: Monarch (318MHz, 433MHz, 295MHz) and Stingray (318MHz, 433MHz, 295MHz)
The Transmitter Solutions WIE318-L delivers reliable multi-frequency Wiegand reception backed by a 5-year warranty.
