Locinox MAMMOTH180-9005 Hydraulic Swing Gate Closer & Hinge

Overview

The Locinox MAMMOTH180-9005 combines a hydraulically damped closer with the Dino double-bearing hinge in a single unit, purpose-built for heavy-duty swing gates. The Active Thermal System maintains a constant closing speed regardless of weather conditions, while the weatherproof aluminum housing ensures lasting durability in exterior environments. The Dino hinge is included.

Key Features

• 180° self-closing double bearing hinge with adjustable closing speed and final snap
• Patented hydraulic damping for consistent closing speed
• Active Thermal System — constant closing speed unaffected by weather conditions
• Weatherproof aluminum housing designed for exterior use
• ADA compliant (< 5 lbs; max 16 Nm) from gate widths of 3 ft. or more
• Supports gates up to 330 lbs and 5 ft. wide
• Suitable for left and right opening gates
• Vandal and tamper proof
• Fast and easy installation with Quick-Fix
• Robust, stylish design with high quality components

Specifications

• Max Gate Weight: 330 lbs
• Max Gate Width: 5 ft.
• Opening Angle: 180°
• ADA Compliance: < 5 lbs; max 16 Nm (gate widths 3 ft. or more)
• Installation Gap: 9/16" min up to 1-3/8" max (ornamental)
• Height Adjustability: 9/16"
• Housing Material: Aluminum
• Color: Black

Compatibility

• Compatible with CLB-MAMMOTH Chain Link Brackets

The Locinox MAMMOTH180-9005 is a professional-grade solution for demanding swing gate applications requiring reliable, self-closing performance.
