Transmitter Solutions IGAZEREKIT-UL Wireless Safety Edge Kit

Overview

The Transmitter Solutions IGAZEREKIT-UL is the iGAZE® RE KIT wireless safety edge system intended as a safety device for automated gates and rolling doors. The system includes one radio receiver control (RC00900) with 2 output relays connected to the operator, and supports up to 2 radio transmitters (TC00900) per relay. Transmission is bi-directional and operates on 902–928 MHz.

Key Features

• Functions with mechanical and resistive edges simultaneously
• 164 feet of range between receiver and transmitter
• 2 relay outputs
• Supports up to 4 edges per relay
• Battery powered transmitter with up to 1 year battery life in normal mode and up to 2 years in low power mode
• Receiver enclosed in a water tight box
• Receiver includes 2 Auto-test controls for compatible operators

Specifications

• Frequency: 902–928 MHz (bi-directional)
• Range: 164 feet
• Relay Outputs: 2
• Edges per Relay: 4
• Transmitter Battery Life: Up to 1 year (normal mode), up to 2 years (low power mode)
• Receiver Enclosure: Water tight box

Compatibility

• Accepts mechanical safety edges with N.O. or N.C. controls
• Accepts resistive safety edges: 8.2KΩ and 10KΩ

The Transmitter Solutions IGAZEREKIT-UL delivers reliable wireless safety edge performance for automated gate applications.
