Transmitter Solutions IGAZER50LR-NC Reflective Photo Eye

Overview

The Transmitter Solutions IGAZER50LR-NC is a long-range retro-reflective photo beam designed for gate operator applications. It accepts a wide input voltage range of 12–250 VAC/DC (non-polarity), features a PC upper casing with anti-fog/dew/rain properties, and is housed in a NEMA 4X (IP-66) rated enclosure with cable gland for reliable weatherproof installation.

Key Features

• Long range – 50 ft. external sensing range
• Compatible with N.C. and 10K gate operators
• Retro-reflective design with round reflector – diameter 3-1/4"
• NEMA 4X (IP-66) waterproof enclosure with cable gland
• Infrared LED element – wavelength 940 nm
• PC upper casing with anti-fog, anti-dew, and anti-rain properties
• Twin color LED indicator for beam alignment feedback
• Tamper switches included

Specifications

• Type: Retro-reflective
• Input Voltage: 12–250 VAC/DC (non-polarity)
• Tx LED Element: Infrared LED / Wavelength 940 nm
• Beam Spreading Angle: 5°
• Contact Capacity: 0.5A / 120VAC (1A / 30VDC)
• Response Time: 10 msec
• Delay Time of Relay: 100 msec
• Sensing Range: 50 feet
• LED Indicators:
  • Red LED off: Beam aligned
  • Red LED on: Beam broken
  • Red LED flash: Beam alignment signal weak (re-align)
  • Green LED on: Beam aligned properly
• Wiring Connection: Terminal block / Cable gland (NEMA 4X / IP-66)
• Housing Material: PC
• IP Rating: NEMA 4X (IP-66)
• Operating Temperature: -13°F to 140°F
• Storage Temperature: -31°F to 176°F
• Dimensions: 4-5/8" (L) × 2-1/4" (W) × 2-1/4" (D)

Compatibility

• Works with N.C. and 10K gate operators

The Transmitter Solutions IGAZER50LR-NC delivers dependable long-range detection with robust weatherproof construction for professional gate operator installations.
