Transmitter Solutions IGAZER50LRUL10KNC Photo Beam Sensor

Overview

The Transmitter Solutions IGAZER50LRUL10KNC is a monitored photoelectric beam sensor designed for use with Normally Closed and 10K gate operators. It features a retro-reflective design with a long range of up to 50 ft., housed in a PC upper casing built to withstand demanding outdoor conditions.

Key Features

• Long range: Up to 50 ft. external range
• Retro-reflective photoelectric beam design
• Compatible with N.C. and 10K gate operators
• IP66 / NEMA 4X weatherproof protection
• Infrared LED element
• PC upper casing — anti-fog, anti-dew, anti-rain
• Round shape reflector — Diameter 3-1/4"
• Twin color LED indicator for beam alignment
• Tamper switches included
• Conforms to UL STD 325; Certified to CSA STD C22.2 #247

Specifications

• Type: Retro-reflective
• Input Voltage: 12–250 VAC/DC (non-polarity)
• Beam Spreading Angle: 5°
• Contact Capacity: 0.5A / 120VAC (1A / 30VDC)
• Response Time: 10 msec
• Delay Time of Relay: 100 msec
• Additional Function: Tamper switches
• Housing Material: PC
• IP Rating: NEMA 4X (IP-66)
• Operating Temperature: -13°F to 140°F
• Dimensions: 4-5/8" (L) x 2-1/4" (W) x 2-1/4" (D)

Compatibility

• Works with Normally Closed (N.C.) gate operators
• Works with 10K gate operators

The Transmitter Solutions IGAZER50LRUL10KNC delivers reliable, long-range beam detection with robust weatherproof construction and tamper protection for professional gate access control applications.
