AES EL00IG-RAD-KLT Inground Loop Kit Presence Mode with Tran
The AES EL00IG-RAD-KLT is an inground wireless loop kit in presence mode, featuring dual sensor technology (Magnetic field and Radar detection), 128-bit encryption, and up to 50 yards range. Kit includes the e-Loop, Trans-200 transceiver, and magnet.
Overview
The AES EL00IG-RAD-KLT is an inground wireless access control loop kit designed to recess seamlessly into pavement for a flush, unobtrusive profile. Sharing the same feature set as the surface commercial e-LOOP, the inground unit eliminates tripping hazards and suits high-traffic environments such as busy parking lots and loading docks. The kit ships complete with the e-Loop, Trans-200 transceiver, and magnet.
Key Features
- Presence mode operation
- Dual sensor technology — Magnetic field and Radar detection
- 128-bit encryption for high security
- Up to 50 yards wireless range
- Compact inground profile: 2.1" diameter x 3.4" high, rated IP68
- Not affected by ground movement
- 14,500 mA battery providing up to 6–10 years of battery life
- Top access for battery replacement
- Quick and easy installation
- LCD display on Trans-200 for simple menu navigation
- High sensitivity 433 MHz receiver (-126 dBm) with 20 dBm transmission output
- External SMA connector for optional long-range antenna connection
- Unique lock-out function allowing you to lock out entry buttons, e-Loops, and keypads
- Ability to delete individual remote devices
- Test mode for relay outputs, signal strength, and interference
- Relay can be set to Pulse, Latch, or Hold mode
- 200 code storage with remote ID selection
Trans-200 Transceiver Specifications
- Input Voltage: Wide range from 10V to 36V AC/DC
- Standby Current Draw: 4.5 mA (selectable ultra-low standby mode — ideal for solar applications)
- Frequency: 433 MHz
- Relay Outputs: 2 relay outputs, NC/NO/COM
- Code Storage: 200 codes with remote ID selection
- Bandwidth: 250 Hz
- Encryption: 128-bit AES
e-Loop Specifications
- Diameter x Height: 2.1" x 3.4"
- IP Rating: IP68
- Battery: 14,500 mA — up to 6–10 years life
- Range: Up to 50 yards
The AES EL00IG-RAD-KLT delivers professional-grade wireless access control with a discreet inground installation — purpose-built for commercial environments that demand both performance and aesthetics.
