AES EL00IG-RAD-KT Inground Presence E Loop Kit with eTrans10
The AES EL00IG-RAD-KT is an inground wireless presence loop kit featuring dual sensor technology (Magnetic field and Radar detection), 128-bit encryption, and up to 50 yards range. Kit includes the e-Loop, eTrans100 transceiver, and magnet.
Overview
The AES EL00IG-RAD-KT is an inground wireless presence loop kit designed to integrate seamlessly into pavement for a flush, unobtrusive profile. Sharing the same features as the surface commercial e-LOOP, the inground unit eliminates tripping hazards and offers a clean aesthetic while delivering robust performance in high-traffic environments such as busy parking lots and loading docks. The kit includes the EL00IG-RAD e-Loop, the eTrans100 two-channel transceiver, and a magnet.
Key Features
- Presence mode operation
- Dual sensor technology — Magnetic field and Radar detection
- 128-bit encryption for high security
- Recesses into driveway with a compact profile — 2.1" diameter x 3.4" high (IP68 rated)
- Not affected by ground movement
- Up to 50 yards range
- 14,500 mA battery providing up to 6–10 years of battery life
- Top access for battery changes
- Quick and easy installation
- Available in both Presence mode and Exit mode
eTrans100 Transceiver Specifications
- Channels: 2-channel transceiver
- Power input: 10–28V AC or 10–36V DC
- Frequency: 433.39 MHz
- Standby current draw: 12 mA standard; selectable LDC mode at 4.5 mA for solar applications
- Storage: Stores 2 x e-Loops and 50 x remotes per channel
- Relay outputs: 2 relay outputs — configurable to Pulse, Hold, or Latch mode
- Code storage: 200 codes with remote ID selection
- Long range with SMA connector for external antenna options
- Ability to delete individual remote devices
- Unique lock-out feature for entry buttons, e-Loops, and keypads
- Test mode for relay outputs, signal strength, and interference
- Selectable ultra-low standby power consumption of 4.5 mA, ideal for solar applications
e-Loop (EL00IG-RAD) Specifications
- Dimensions: 2.1" diameter x 3.4" high
- IP Rating: IP68
- Battery: 14,500 mA — up to 6–10 years life
- Range: Up to 50 yards
- Encryption: 128-bit
- Frequency: 433.39 MHz
The AES EL00IG-RAD-KT delivers a discreet, durable wireless loop solution purpose-built for commercial access control applications.
