EMX Industries 1112-K Infrared Thru-Beam Photoeye with Gray
The EMX Industries 1112-K (IRB-325 with Gray Hoods Kit) is a UL325-2018 compliant external entrapment protection device (Type B1) for automatic gates, featuring an operating range of 6 to 65 feet and powered by 12V to 24V DC or AC.
Overview
The EMX Industries 1112-K is the IRB-325 thru-beam photoeye bundled with gray powder coated steel hoods. Designed as a non-contact, Type B1 external entrapment protection device for automatic gates, it is UL325-2018 compliant and compatible with operators that require NC monitoring. The NEMA 4X enclosure delivers the durability demanded by safety applications, while the included powder coated steel hoods guard against environmental exposure and accidental contact damage from vehicles and equipment.
Key Features
- External entrapment protection device, Type B1, non-contact sensor
- Operating range: 6 to 65 feet
- Powered by 12V to 24V DC or AC
- UL325-2018 compliant with NC monitoring support
- Housing rated UL and CSA Type 4, NEMA 4X, 3, 3R, 12, 13
- Gray powder coated steel protective hoods included (set of 2)
Specifications
- Operating Range: 6 to 65 feet
- Power Supply: 12V to 24V DC or AC, 150mA
- Current Consumption (Receiver): 12 VDC standby/detect 33mA/25mA; 24VAC/DC standby/detect 56mA/38mA
- Current Consumption (Transmitter): 47mA
- Relay Contact Rating: 1A @ 30VDC
- Operating Temperature: -40°F to +170°F
- Housing Dimensions: 5.03" (128mm) H x 3.06" (78mm) W x 3.02" (77mm) D
- Hood Dimensions: 6.7" (170mm) x 3.3" (84mm) x 4.4" (112mm)
- Hood Material: Gray powder coated steel
The EMX Industries 1112-K delivers reliable, certified entrapment protection with rugged housing and protective hoods ready for demanding access control environments.
