EMX Industries 1250-1 Photoelectric Safety Sensor IRB-4X2
The EMX Industries 1250-1 (IRB-4X2) is a through-beam photoeye designed for use as a safety, reversing, or opening device with automatic operators. Features an IP65 enclosure and a range of 5 to 115 ft (35 m).
Overview
Building on the success of the original IRB-4X, the EMX Industries 1250-1 (IRB-4X2) delivers advanced features in a smaller and more convenient package. This photoeye is designed for use as a safety, reversing, or opening device in conjunction with automatic operators, and will work with any control board that accepts a dry contact input. Suitable for use with garage doors, rolling doors, parking barriers, and other equipment. Not for use in applications requiring UL325 compliance.
Key Features
- Works without lenses for easy alignment
- Electronic sunlight filter
- Automatic compensation for temperature changes
- Capable of penetrating 70% obstruction due to fog, steam, and spray
- Immune to vibration
- Does not require additional signal amplifiers or relay boxes
- IP65 enclosure rating
Specifications
- Range: 5 to 115 ft (35 m)
- Power: 12–24 volts AC or DC
- Current: TX = 37mA, RX = 23mA standby, 17mA detect
- Response Time: 10mS max
- Operating Temp: -40°F to +170°F
- Relay Contact Rating: 1A @ 24VDC or 120VAC
- Dimensions: 3.6" (91 mm) x 2.9" (74 mm) x 2.9" (74 mm)
- Gain Adjustment: Potentiometer
- Conduit Hole Size: 0.83" (21.3 mm) — large enough for 1/2 inch NPT
Compatibility
Compatible with any control board that accepts a dry contact input. Suitable for garage doors, rolling doors, and parking barriers.
The EMX Industries 1250-1 is a reliable, easy-to-install photoeye solution for a wide range of access control and gate safety applications.
