FAAC 116037 J275 800mm Hydraulic Auto SS Bollard

FAAC J275 Hydraulic-Automatic V2 Traffic & Perimeter Security Bollard (800mm) — Stainless Steel

The FAAC J275 Hydraulic-Automatic V2 Bollard (Part: 116037) is engineered for intensive use in commercial, industrial, and urban restricted access areas. Featuring an integrated hydraulic drive, this retractable bollard delivers rapid, silent operation and seamlessly integrates with existing access control systems. It is an ideal solution for government buildings, corporate security perimeters, and high-risk zones requiring robust vehicle restriction.

Key Features

• Hydraulic Automatic Operation: Designed for high-frequency use with fast and efficient cycling, suitable for demanding traffic management environments.
• Integrated Hydraulic Unit: Simplifies installation and ongoing maintenance by housing the hydraulic drive within the bollard assembly.
• "Gentle Stop" Function: Ensures smooth deceleration during the lowering cycle, reducing mechanical stress and enhancing operational longevity.
• LED Flashing Light Ring & Acoustic Buzzer: Equipped with a built-in flashing LED light ring and acoustic buzzer for enhanced visibility and pedestrian/vehicle awareness during operation.
• AISI 316L Stainless Steel Construction: The cylinder is constructed from 6mm thick AISI 316L satin-finished stainless steel, providing superior corrosion resistance, weather durability, and an attractive appearance.
• Seamless Access Control Integration: Readily connects with existing access control and security management systems for centralized vehicular traffic management.

Specifications

• Manufacturer: FAAC
• Part Number: 116037
• Model: J275/800 Bollard Auto SS V2
• Bollard Height: 800mm
• Bollard Diameter: 275mm
• Wall Thickness: 6mm
• Material: AISI 316L satin-finished stainless steel
• Operation Type: Hydraulic-Automatic
• Safety Features: Flashing LED light ring, acoustic buzzer, "Gentle Stop" function

Required Parts & Optional Accessories

Please note: for a proper and functional installation, you must purchase the bollard along with the required supporting components. The following parts are necessary:

• FAAC Bollard Pit for J275 Retractable Bollards — Part: 1161001
• FAAC Bollard Pit Extension for J275 HA V2 800 Models — Part: 1161011
• FAAC Bollard Control Unit for Hydraulic Bollards — Part: 117300

Optional accessories are also available to enhance performance and protection:

• FAAC Bollard Pit Heater for J275 HA V2 and 2K20 Models — Part: 116200
• FAAC Bollard Pit Cover for J275 Series Bollards — Part: 116201

Applications

The FAAC J275 V2 bollard is suitable for a wide range of perimeter security and traffic control applications, including:

• Government and municipal buildings
• Corporate campuses and office complexes
• Military installations and high-risk zones
• Urban pedestrian zones and restricted access areas
• Commercial and industrial facility entrances

Backed by FAAC's reputation for engineering excellence, the J275 Hydraulic-Automatic V2 bollard delivers dependable, long-term performance in the most demanding security environments. Its combination of robust stainless steel construction, integrated hydraulic technology, and advanced safety features makes it a trusted choice for professional perimeter protection.
