FAAC 117051 EFO Retractable Security Bollard

FAAC JS48 HA EFO Retractable Security Bollard (117051)

The FAAC JS48 Hydraulic-Automatic Emergency Fast Operation (EFO) Retractable Security Bollard is engineered for high-security environments demanding rapid, reliable vehicle access control. Designed for critical infrastructure such as military bases, airports, government buildings, and other high-risk facilities, this crash-rated bollard delivers swift deployment when every second counts. Its integrated hydraulic power unit and emergency fast operation capability make it one of the most responsive security bollards available.

Key Features

• Emergency Fast Operation (EFO): Allows rapid bollard deployment in under 1.5 seconds, ensuring immediate response to security threats and unauthorized vehicle intrusion attempts.
• Hydraulic-Automatic Operation: The integrated hydraulic power unit provides smooth, dependable raising and lowering cycles for continuous high-security access control.
• High-Strength Steel Construction: Features a robust steel cylinder with a 275mm diameter and 1000mm exposed height, delivering exceptional impact resistance against vehicular attacks.
• Painted Steel Finish: The durable painted finish protects against corrosion and weathering, ensuring long-term performance in demanding outdoor environments.
• Crash-Rated Certification: Certified to PAS 68, IWA 14-1, and ASTM F2656 standards, providing independently verified protection against hostile vehicle attacks.
• Retractable Design: Fully retractable into the ground when not deployed, allowing authorized vehicle passage and maintaining aesthetic site appearance.

Specifications

• Manufacturer: FAAC
• Part Number: 117051
• Model: JS48 HA EFO
• Operation Type: Hydraulic-Automatic with Emergency Fast Operation
• Bollard Height (Exposed): 1000mm
• Bollard Diameter: 275mm
• Material: High-strength steel
• Finish: Painted steel
• Emergency Rise Time: Less than 1.5 seconds
• Certifications: PAS 68, IWA 14-1, ASTM F2656

Required Parts for Installation

Please note that the following components are required for proper and functional installation of the JS48 bollard and must be purchased separately:

• FAAC Bollard Control Unit for Hydraulic Bollards — Part: 117300
• FAAC Bollard Pit for JS48 and JS80 Hydraulic Bollards — Part: 117901

Optional Accessories

• Bollard Pit Cover for JS48 and JS80 — Part: 117903
• Emergency Manual Pump for JS48 and JS80 — Part: 117905
• Pit Heater Kit for J200, JS48 & JS80 — Part: 117906

Applications

The FAAC JS48 HA EFO bollard is ideally suited for deployment at military installations, airports, embassies, government facilities, critical infrastructure perimeters, and any location where rapid, certified vehicle mitigation is essential. Its crash-rated certifications to international standards ensure it meets the most stringent security requirements worldwide.

Backed by FAAC's reputation for engineering excellence in access control and perimeter security, the JS48 HA EFO bollard delivers the performance, durability, and rapid response capability that high-security applications demand. Trust in a solution that is independently tested and certified to protect people and property when it matters most.
