FAAC 117251 JS 48 HA EFO Stainless Steel Bollard
The FAAC 117251 is a hydraulic-automatic retractable bollard with Emergency Fast Operation (EFO) deploying in under 1.5 seconds, rated P1 and certified to PAS 68, IWA 14-1, and ASTM F2656 standards.
Overview
The FAAC 117251 JS 48 HA EFO is a high-security, crash-rated retractable bollard engineered for environments requiring rapid vehicular threat response. It features a 1000 mm high, 275 mm diameter high-strength steel cylinder enclosed in a satin-finished stainless steel protective sleeve. The integrated hydraulic power unit delivers standard rise in approximately 6 seconds, while the Emergency Fast Operation (EFO) system reduces deployment to less than 1.5 seconds. Certified to PAS 68:2013, IWA 14-1:2013, and ASTM F2656-07, it is rated P1 with one bollard installed and is capable of stopping a 16,500 lb truck traveling at 48 km/h.
Key Features
- Emergency Fast Operation (EFO): Deploys in under 1.5 seconds for rapid threat response
- Hydraulic-automatic operation suitable for intensive use
- Integrated hydraulic power unit for simplified installation and maintenance
- Interchangeable protective sleeve with satin-finished stainless steel for enhanced durability
- Equipped with a reflective strip (white), LED flashing light ring, and acoustic buzzer for visibility and safety
- Manual lowering via hydraulic manual override with release key
- Hydraulic lock in raised position during power outages
- Protection class IP67
Specifications
- Model: JS 48 HA EFO
- Part Number: 117251
- Bollard Type: Hydraulic-Automatic
- Height: 1000 mm (39.4 in)
- Cylinder Diameter: 275 mm
- Rise Time: Approximately 6 seconds (standard); less than 1.5 seconds (EFO)
- Descent Time: Approximately 2 seconds
- Input Voltage: 220–240V AC, 50/60 Hz
- Crash Rating: P1 (with 1 bollard installed)
- Certifications: PAS 68:2013, IWA 14-1:2013, ASTM F2656-07
- Protection Class: IP67
- Finish: Satin-finished stainless steel (Steel Silver)
- Reflective Strip Color: White
Compatibility
- Compatible with FAAC Bollard Control Unit for Hydraulic Bollards — 117300
- Compatible with FAAC Bollard Pit for JS48 and JS80 Hydraulic Bollards — 117901
The FAAC 117251 delivers certified crash protection and rapid emergency deployment for the most demanding high-security perimeter applications.
