FAAC 117551 JS80 HA EFO Retractable Security Bollard

FAAC JS80 HA EFO Retractable Security Bollard (117551)

The FAAC JS80 Hydraulic-Automatic Emergency Fast Operation (HA EFO) Retractable Security Bollard is engineered for high-security environments where rapid deployment is critical. Designed to protect critical infrastructure, government facilities, embassies, and other high-risk zones, this crash-rated bollard combines a high-speed hydraulic system with robust painted steel construction to deliver instant perimeter protection against vehicle-borne threats.

With its emergency fast operation capability, the JS80 HA EFO can be deployed in seconds, ensuring immediate response to security incidents. The hydraulic-automatic mechanism provides smooth, controlled raising and lowering during normal access operations, while the emergency mode enables rapid bollard deployment when threats are detected.

Key Features

• Emergency Fast Operation (EFO): Rapid deployment capability designed for instant response in high-risk security situations.
• Hydraulic-Automatic System: Provides reliable, controlled bollard operation for everyday access management and emergency scenarios.
• Crash-Rated Performance: Certified to PAS 68, IWA 14-1, and ASTM F2656 standards — tested to stop a 16,500 lb truck traveling at 80 km/h.
• Heavy-Duty Painted Steel Construction: 275mm diameter painted steel body delivers superior impact resistance and long-term durability.
• 1000mm Bollard Height: Provides a visible and effective physical barrier above ground level.
• Retractable Design: Bollard fully retracts below ground to allow authorized vehicle passage when lowered.

Specifications

• Manufacturer: FAAC
• Part Number: 117551
• Model: JS80 HA EFO
• Operation Type: Hydraulic-Automatic with Emergency Fast Operation
• Bollard Height (Above Ground): 1000mm
• Bollard Diameter: 275mm
• Material: Painted Steel
• Crash Rating Certifications: PAS 68, IWA 14-1, ASTM F2656
• Impact Rating: Stops a 16,500 lb vehicle at 80 km/h

Required Parts & Optional Accessories

For a complete and functional installation, the following required parts must be purchased separately:

• FAAC Bollard Control Unit for Hydraulic Bollards (Part: 117300)
• FAAC Bollard Pit for JS48 and JS80 Hydraulic Bollards (Part: 117901)

The following optional accessories are also available to enhance your installation:

• Bollard Pit Cover for JS48 and JS80 Hydraulic Bollards (Part: 117903)
• Emergency Manual Pump for JS48 and JS80 Hydraulic Bollards (Part: 117905)
• Bollard Pit Heater Kit for J200, JS48 & JS80 Hydraulic Models (Part: 117906)

Applications

The FAAC JS80 HA EFO is ideally suited for protecting high-value and high-risk locations, including government buildings, embassies, military installations, critical infrastructure, airports, financial institutions, and other sites requiring certified hostile vehicle mitigation (HVM) measures.

Backed by FAAC's proven expertise in access control and perimeter security, the JS80 HA EFO retractable bollard delivers the performance, reliability, and certified crash protection demanded by the most security-sensitive applications worldwide.
