FAAC 117751 Stainless Steel Retractable Bollard

FAAC JS80 HA EFO Stainless Steel Retractable Bollard

The FAAC JS80 HA EFO (Hydraulic-Automatic Emergency Fast Operation) is a high-security, crash-rated retractable bollard engineered for rapid-response environments. Constructed from durable stainless steel and standing 1000mm above grade with a 275mm diameter, this bollard delivers top-tier perimeter protection for embassies, military installations, government facilities, and critical infrastructure. Its high-speed hydraulic system enables emergency deployment in seconds, ensuring immediate security when it matters most.

Key Features

• Emergency Fast Operation (EFO): High-speed hydraulic system allows rapid deployment in critical situations, providing immediate perimeter lockdown.
• Stainless Steel Construction: Premium stainless steel body delivers exceptional strength, impact resistance, and long-lasting corrosion protection in all weather conditions.
• Crash-Rated Certifications: Certified to PAS 68, IWA 14-1, and ASTM F2656 standards — capable of stopping a 16,500 lb truck traveling at 80 km/h.
• Hydraulic-Automatic Operation: Fully automatic hydraulic raise and lower cycle for seamless, hands-free traffic management.
• Reflective Strip: Integrated reflective strip enhances visibility for vehicles and pedestrians in low-light conditions.
• 1000mm Visible Height: Provides a commanding physical and visual barrier above ground level.

Specifications

• Manufacturer: FAAC
• Part Number: 117751
• Model: JS80 HA EFO
• Material: Stainless Steel
• Bollard Height (Above Grade): 1000mm
• Bollard Diameter: 275mm
• Operation Type: Hydraulic-Automatic with Emergency Fast Operation
• Crash Rating Certifications: PAS 68, IWA 14-1, ASTM F2656
• Impact Resistance: Rated to stop a 16,500 lb vehicle at 80 km/h

Required Parts for Installation

Please note that both the bollard and the following required parts must be purchased for a proper and functional installation:

• FAAC Bollard Control Unit for Hydraulic Bollards — Part: 117300
• FAAC Bollard Pit for JS48 and JS80 Hydraulic Bollards — Part: 117901

Optional Accessories

• FAAC Bollard Pit Cover for JS48 and JS80 Hydraulic Bollards — Part: 117903
• FAAC Bollard Emergency Manual Pump for JS48 and JS80 Hydraulic Bollards — Part: 117905
• FAAC Bollard Pit Heater Kit for J200, JS48 & JS80 Hydraulic Models — Part: 117906

Applications

The FAAC JS80 HA EFO is purpose-built for the most demanding security environments. Ideal applications include embassies, military bases, government buildings, airports, data centers, and any facility requiring rapid-response hostile vehicle mitigation. Its stainless steel finish also makes it well-suited for architecturally sensitive urban locations where both aesthetics and security are paramount.

Backed by internationally recognized crash-test certifications and FAAC's proven expertise in access control solutions, the JS80 HA EFO stainless steel retractable bollard represents a reliable, high-performance investment in perimeter security.
