KICKER ROLLER W/ THREADED SHAFT
SKU
aom-15b
The All-O-Matic 15B is a Kicker Roller with Threaded Shaft — jamb track hardware designed for California Lift Gates. The kicker wheel bracket is welded to the jamb and centered with the gate side rails.
Overview
The All-O-Matic 15B Kicker Roller with Threaded Shaft is jamb track hardware engineered for California Lift Gate installations. The kicker wheel bracket mounts to the jamb at a specified centerline height and is welded in place, with the shaft then welded to the kicker bracket once centered with the gate side rails.
Key Features
- Threaded shaft design for precise positioning
- Bracket centers with gate side rails upon installation
- Shaft is welded to kicker bracket after alignment
Specifications
- Centerline of kicker wheel — Jumbo gate: 27"
- Centerline of kicker wheel — Heavy Jumbo gate: 30"
- Top of J-Track (Mark A) — all configurations: 2"
Installation Notes
- Align center of kicker wheel bracket with Mark B on the jamb as shown in the installation diagram
- Clamp and weld bracket to jamb, then center kicker wheel with gate side rails before welding shaft to kicker bracket
- Verify marks on both jamb sides are level before welding — uneven marks will make gate balancing impossible
The All-O-Matic 15B is a purpose-built component for reliable California Lift Gate jamb track assemblies.
