LiftMaster LA412PKGUL Swing Solar Gate Opener

Overview

The LiftMaster LA412PKGUL is an all-in-one solar swing gate opener designed for locations where AC power is unavailable or impractical. It operates on a 12 Vdc battery run / solar charge system with a maximum solar input of 12 Vdc at 30 watts. The system is housed in a commercial-duty cast aluminum enclosure and powered by a P3 12VDC continuous-duty motor with a precision-machined all-metal worm gear drive. It is UL 325 & UL 991 listed for Class I, II, III, and IV applications.

Key Features

• Solar-Ready System: Operates entirely on solar charge with no AC supply required. Supports up to approximately 100 cycles per day on solar power and up to 126 days standby.
• Security+ 2.0®: Encrypted signal technology to virtually eliminate interference and provide extended range.
• Inherent Reversing Sensor: Detects obstructions or increased loads — reverses the gate when closing, or stops and reverses when opening.
• Wireless Dual-Gate Communication: Eliminates the need for expensive conduit runs or driveway cuts.
• Bi-Part Delay: Monitors and adjusts the speed and position of each wing to ensure the primary gate closes last.
• Synchronized Close: Simultaneously closes both gates.
• Anti-Tailgate: Gate pauses when closing as a vehicle pulls onto the interrupt or breaks the photo beam; continues closing once the vehicle backs up.
• Fire Department Compliance: Allows the gate to auto-open upon loss of AC power or battery depletion.
• Surge Suppression: Industrial surge and lightning protection against strikes up to 50 feet away.
• Keyed Manual Disconnect: Allows manual gate operation when unlocked.
• LED Diagnostic Display: Simplifies installation and troubleshooting.
• Programmable Auxiliary Relays: Easily add features such as warning lights or alarms.
• Soft Start/Stop and Mid-Travel Reversal: Extends operator and hardware life in high-cycle and heavy-gate applications (requires optional Expansion Board).
• myQ® Connectivity: Monitor and control the gate remotely via the myQ® smartphone app (requires additional Internet Gateway unit). Includes real-time alerts and remote close capability.
• Cover: High-density, UV-resistant polycarbonate 2-piece cover for heat and corrosion resistance.
• Chassis: Constructed with 1/4 in. gold zinc-plated steel for rust prevention.

What's Included

• Primary Arm LA412DC
• Battery Backup with control board
• Monitored Retro Reflective Photo Eye LMRRUL
• Solar Panel

Specifications

• Usage Classification: Class I (UL 325 & UL 991 listed – Class I, II, III, and IV)
• Main AC Supply: N/A — Solar Only
• System Operation Voltage: 12 Vdc Battery Run / Solar Charge
• Accessory Power: 24 Vdc, 500mA max for ON + SW (switched)
• Solar Power Max: 12 Vdc at 30 watts max.
• Maximum Gate Weight/Length:
  • 850 lbs. (385.6 kg) / 10 ft (3.0 m)
  • 750 lbs. (340.2 kg) / 12 ft (3.7 m)
  • 650 lbs. (294.8 kg) / 14 ft (4.3 m)
  • 550 lbs. (249.5 kg) / 16 ft (4.9 m)
• 90 Degree Travel Time: Opens 90° in 23–24 seconds
• Maximum Travel Range: 115 degrees
• Recommended Cycle Rate: 100 cycles
• Maximum Duty Cycle: 4 min on
• Standby Power: Up to 126 days
• Operating Temperature (without heater): -4°F (-20°C) to 140°F (60°C)
• Operating Temperature (with optional heater HTR): -40°F (-40°C) to 140°F (60°C)
• Monitored Safety Inputs: 3 Main Board, 3 Optional Expansion Boards
• Expansion Board: Optional (Model K1D8387-1CC)
• Operator Weight: Actuator arm 19 lbs.; standard control box 13 lbs.
• Dimensions: Height: 6.06 in.; Width: 37.96 in.; Depth: 3.93 in.
• Warranty: 2-year operator warranty

Compatibility & Optional Accessories

• Outswing applications require LiftMaster PUSH TO OPEN Bracket Kit Model 50-19503 (not included).
• For external loops, plug-in loops, auxiliary relays, and additional inputs, add Model K1D8387-1CC Expansion Control Board.
• Integrates with LiftMaster Access Control Technology, including the CAPXL Connected Access Portal and the CAP2D Door Controller.
• myQ® smartphone app monitoring and control available with an additional Internet Gateway unit.

The LiftMaster LA412PKGUL delivers dependable, solar-powered swing gate operation with the connectivity, safety, and durability required for professional installations.
