LiftMaster CAP4AP Smart Access Controller
The LiftMaster CAP4AP is a cloud-based Smart Access Controller featuring an outdoor-rated enclosure (IP54/IK07), plug-and-play Wi-Fi and PoE connectivity, and support for up to 4 gates or doors.
Overview
The LiftMaster CAP4AP Smart Access Controller delivers a centralized, cloud-based platform for secure, intelligent access control across properties of all types. Designed for outdoor and compact installations, it connects gates and amenity areas — such as tennis courts, pools, and package rooms — to a secure, cloud-connected platform. Its outdoor-rated polycarbonate enclosure, plug-and-play Wi-Fi, and PoE support help reduce wiring complexity and simplify placement.
Key Features
- Plug-and-play Wi-Fi and PoE support — reduces wiring complexity
- Outdoor-rated enclosure — IP54 and IK07 rated for flexible placement
- Cloud-based diagnostics and remote monitoring — troubleshoot and maintain systems from anywhere
- Local storage — maintains operation during network outages
- Real-time health indicators — LED status lights provide instant feedback
- OSDP encrypted communication — secure, tamper-resistant data transmission
- myQ Integration — manage everything through the myQ Community platform
- 4 relays, 4 supervised inputs, 2 Wiegand inputs, 4 OSDP inputs
- Minimal wiring requirements with fully contained wiring for a clean, professional finish
- Supports industry-standard protocols and flexible relay logic
- Modular design for scalable, multi-building deployments
Specifications
- Outdoor Rating: IP54 and IK07
- Local User Capacity: 50,000
- Event History: 50,000
- Max Gates/Doors Controlled: 4
- Wiegand Input: 2
- Relay Output: 4 relays (inputs to outputs mapping configurable via Advanced Configuration in myQ Community Web Portal)
- Wiegand Output Data Format: 26 credentials or passthrough
- Power Supply: 24VDC (power adapter provided) or PoE
- Operating Temperature: -4°F to 122°F (-20°C to 50°C)
- Dimensions: 9.25" H x 10.29" W x 2.58" D
- Product Weight: 4.82 lbs
- Enclosure Material: Polycarbonate
Compatibility
- Compatible with myQ Community Web Portal and myQ Smartphone App
Warranty
- Parts: 2 years
- Hardware: 2 years
- Motor: Lifetime
The LiftMaster CAP4AP is built for professional integrators who need a reliable, scalable, and intelligently connected access control solution for gates and amenity areas.
