LiftMaster CAP4EXPND Smart Access Expansion Board

Overview

The LiftMaster CAP4EXPND Smart Access Expansion Board extends the capabilities of the LiftMaster Smart Access Controller Panel (CAPXAP) and its control board (CAPXAP-CNTL). Each CAP4EXPND board adds capacity for controlling additional gates, doors, or devices, and also serves as the service kit for the LiftMaster Smart Access Controller (CAP4AP).

Key Features

• 4 Relay Outputs – for controlling additional doors, gates, or devices
• 4 Supervised Inputs – for monitored door contacts or request-to-exit devices
• 2 Wiegand Inputs – for connecting card readers or keypads
• Controls up to 4 gates or doors per board
• Wiegand output supports 26 credentials or passthrough data format

Specifications

• Max Gates/Doors Controlled (Each): 4
• Wiegand Inputs: 2
• Relay Outputs: 4
• Operating Temperature: -4°F to 122°F (-20°C to 50°C)
• Wiegand Output Data Format: 26 credentials or passthrough

Compatibility

• Expansion module for the LiftMaster Smart Access Controller Panel (CAPXAP) and control board (CAPXAP-CNTL)
• Serves as the service kit for the LiftMaster Smart Access Controller (CAP4AP)

The LiftMaster CAP4EXPND is the purpose-built expansion solution for scaling your LiftMaster Smart Access system.
