LiftMaster CAPXAP Smart Access Controller Panel

Overview

The LiftMaster CAPXAP Smart Access Controller Panel is designed for integrators who need a scalable, intelligent access control solution. Cloud-connected and Ethernet/Wi-Fi-enabled, the CAPXAP starts with control of up to 4 doors or gates and expands seamlessly to 48+ access points using LiftMaster Smart Access Expansion Boards (CAP4EXPND). It integrates with the myQ Community Web Portal and Smartphone App for unified, cloud-based management.

Key Features

• Cloud-connected platform with Ethernet and Wi-Fi support
• 4 relays, 4 monitored inputs, 2 Wiegand inputs, and 4 OSDP inputs on-board
• Expandable with CAP4EXPND boards — each adds 4 relays, 4 inputs, and 2 Wiegand inputs
• 50,000 local user capacity for uninterrupted access during network outages
• OSDP encrypted communication for secure, tamper-resistant data transmission
• Real-time health indicators via LED status lights
• Cloud-based diagnostics and remote monitoring
• Floor-level elevator control support
• Wiegand Output Data Format: 26 credentials or passthrough
• Minimal wiring with clean, contained layouts

Specifications

• Dimensions: 23.7" H x 18.77" W x 3.6" D
• Product Weight: 22.2 lbs
• Power Supply: 24VDC (power adapter provided)
• Operating Temperature: -4°F to 122°F (-20°C to 50°C)
• Local User Capacity: 50,000
• Max Doors/Gates Controlled: 4 (expandable)
• Wiegand Inputs: 2
• Relay Outputs: 4 relays, expandable using CAP4EXPND boards
• Wiegand Output Data Format: 26 credentials or passthrough
• Outdoor Rating: No
• Parts Warranty: 2 years
• Hardware Warranty: 2 years

Compatibility

• Compatible with the myQ Community Web Portal and Smartphone App
• Expandable with LiftMaster CAP4EXPND Smart Access Expansion Boards

The LiftMaster CAPXAP delivers the cloud intelligence, scalability, and reliability that modern access control installations demand.
