LiftMaster IBG24DCWMC TECHNA DC Industrial Barrier Gate Oper

Overview

The LiftMaster IBG24DCWMC TECHNA DC Industrial Barrier Gate Operator is engineered for high-traffic industrial environments requiring wide-lane coverage up to 24 feet from a single unit. Finished in high-visibility white, it features a purpose-built internal counterbalance system that supports long arm applications without additional parts. A DC brushless continuous duty motor and direct drive system with oil bath gearbox provide reliable, long-lasting performance. The operator ships with 2 x 12V 7Ah batteries for standard battery backup and weighs 159 lbs including bracket and batteries.

Key Features

• Reinforced Counterbalance System: Supports arm applications up to 24 feet. Spring count and handling are adjustable for shorter arm lengths via simple mechanical adjustments.
• Modular Arm Design: Arms ship in segments to expedite shipping and reduce storage requirements. Tested to over 1 million cycles.
• Slow Start/Stop Operation: Extends operator and arm durability.
• Standard Battery Backup: Included 2 x 12V 7Ah batteries ensure seamless operation during power outages. Optional 2 x 12V 33Ah batteries available. Solar kit also available.
• Advanced Connectivity: Built-in Wi-Fi and Ethernet. Connect to myQ Facility or myQ Community via an access control system. Set timers, review error codes, and configure alerts using standard Ethernet or Wi-Fi.
• Color LCD Display Interface: 4-button interface for adding transmitters, adjusting settings, and viewing diagnostics. Includes local event log with 50-event history.
• Control Board: Features five programmable relays, support for monitored safety devices, a standard plug-in loop rack, and multi-vehicle tracking to close the gate right behind a vehicle for seamless access.
• LED Tower: Standard with the TECHNA unit, providing highly visible signals for drivers, including truck traffic.
• Accessory Power: 24VDC 1A output with switched and unswitched power.
• UL Listed: Listed to ANSI/CAN/UL 325 Standard for USA/Canada and certified to NOM/IFETEL Standards for Mexico. Also UL 991 certified — Class I, II, III, IV.
• Aluminum Housing: Aluminum housing with aluminum LED top lid. Removable front cover and hinged lid with lock. Outdoor rating IP65.

Specifications

• Maximum Lane Coverage: 24 feet
• Dimensions (without bracket): 16.6" L x 14.8" W x 47.4" H
• Operator Weight: 159 lbs (includes bracket and 2 x 12V 7Ah batteries)
• Motor: DC Brushless Continuous Duty
• Drive Type: Direct drive with oil bath gearbox
• Voltage: 120VAC Single Phase @ 12.5A, or 240VAC 1PH @ 3.5A
• Rated Load: 12.5A
• Accessory Power: 24VDC 1A output (switched and unswitched)
• Battery Backup: Standard 2 x 12V 7Ah batteries; Optional 2 x 12V 33Ah batteries available
• Open/Close Time: As low as 6 seconds
• Relay Output: 5 programmable relays
• Display: LCD color display with 4-button interface
• Event History: 50 events
• Connectivity: Wi-Fi and Ethernet
• Wireless Frequency: 900MHz
• Soft Start/Stop: Yes
• Operating Temperature (without heater): -4°F (-20°C) to 140°F (60°C)
• Operating Temperature (with optional heater): -40°F (-40°C) to 140°F (60°C)
• Outdoor Rating: IP65
• Mounting: Concrete base via pre-existing keyhole openings
• 3PHCONV Optional Kit: Converts input voltage of 208VAC/230VAC/460VAC/575VAC to output voltage of 120VAC
• myQ Compatibility: myQ Facility with dedicated Parking SAS; myQ Community over 900MHz
• Operator Warranty: 2 years
• Accessory Warranty: 2 years

Compatibility

• Connects to other gate operators via menu interface and programmable relays
• Compatible with myQ Facility and myQ Community (via access control system)
• Standard Ethernet or Wi-Fi connectivity for access control system integration

Please note: Barrier arm is not included with the operator — arms must be ordered separately.
