Lockey 3830-SCMG Mechanical Keyless Knob Lock with Passage F

Overview

The Lockey 3830-SCMG is a mechanical, keyless knob lock built for both exterior and interior applications. It operates without batteries or electronics, offering a single user code with thousands of possible combinations. The auto-locking feature engages automatically while the passage function allows free passage when needed. Oversized knobs on both the exterior and interior provide comfortable operation, and the Satin Chrome Marine Grade finish is built to withstand the elements.

Key Features

• Mechanical, keyless deadlocking spring latch — no batteries or wiring required
• One user code with thousands of possible combinations
• Auto-locking with passage function
• Oversized knob on exterior and interior
• Reversible handing
• Adjustable backset
• Covers standard 2 1/8" hole
• Weather resistant construction
• Suitable for exterior and interior use
• Lifetime Mechanical Warranty

Specifications

• Dimensions: 6 5/16" L x 1 3/4" W x 2 1/4" D
• Total Coverage with Trim Plates: 7" L x 2 1/4" W
• Door Thickness: 1 1/8" to 2"; up to 5" with Extension Kit
• Material: Zinc-plated steel; Teflon coated stainless steel interior components
• Finish: Satin Chrome Marine Grade (SCMG)
• Available Keypad Options: Single Combination, Double Combination (DC)
• Available Finishes: Satin Chrome Marine Grade (SCMG), Jet Black Marine Grade (JBMG), Oil Rubbed Bronze (OIL), Satin Nickel (SN)

Compatibility

• GB2500 Gate Box
• Extension Kit
• T Cover 2500
• Push Pull Guard
• Deadlocking Spring Latch

The Lockey 3830-SCMG delivers reliable, code-based access control with no keys and no power source required.
