EMX Industries 2500-1 LP-D-TEK Low Power Vehicle Detector

Overview

The EMX Industries 2500-1 (LP-D-TEK) was designed for applications where low power consumption is essential. Its <9 mA current draw in both standby and detect modes makes it a strong fit for solar-powered setups and gate operators sharing a power supply among multiple accessories. The unit operates on 12–24 Volts AC/DC and is housed in an extruded anodized aluminum enclosure with an aluminum RF shield.

Key Features

• <9 mA current draw in standby and detect modes — "fail safe"
• Surge protection via Zener Diode / MOV
• Built-in loop isolation transformer
• Built-in loop conditioner
• Aluminum RF shield housing
• Loop diagnostics
• Frequency counter
• 2 output relays (1A, 30 VDC each)
• Automatic tuning on reset or power up
• Automatic tracking for environmental changes

Specifications

• Power Supply: 12–24 Volts AC/DC
• Current Consumption: <9 mA
• Operating Temperature: -40°F to 180°F
• Output Relays: 2 × 1A, 30 VDC
• Loop Input: Transformer isolation, lightning and transient protection (1)
• Loop Inductance Range: 20–2000 uH, Q-factor of 5 or higher
• Tuning: Automatic on reset or power up
• Tracking: Automatic for environmental changes
• Height: 3.25" (83mm)
• Width: 2.56" (40mm)
• Length: 3.65" (90mm)
• Housing: Extruded Anodized Aluminum
• Connector: 86CP11 11-pin male

The EMX Industries 2500-1 delivers reliable, low-power vehicle detection for demanding installations where efficiency and protection are priorities.
