LOWER PIVOT BRACKET
SKU
aom-12
The All-O-Matic 12 Lower Pivot Bracket is jamb track hardware designed for California Lift Gates, welded to the gate side rails to ensure a precise fit between the hardware and J-tracks.
Overview
The All-O-Matic 12 Lower Pivot Bracket is a jamb track hardware component for California Lift Gates. It is welded directly to the gate side rails after the gate is allowed to hang freely from the track rollers, ensuring a proper and accurate fit between the hardware and J-tracks.
Key Features
- Designed to be welded to gate side rails for a secure, precise installation
- Installation method — allowing the gate to hang from rollers before welding — ensures a good fit between hardware and J-tracks
- Compatible with the J-track system used in California Lift Gate assemblies
Installation Notes
- Remove shims from under the gate and allow the gate to hang from track rollers before welding
- Keep the gate flush with jambs during welding
- After welding, J-tracks must be adjusted until parallel with the gate and fastened securely to the building structure
The All-O-Matic 12 Lower Pivot Bracket is a critical component for achieving a properly balanced and smoothly operating California Lift Gate installation.
