LOWER PIVOT PIN RETAINING CLIP
The All-O-Matic 11 Lower Pivot Pin Retaining Clip is jamb track hardware designed for use with California Lift Gates, securing the lower pivot assembly during installation and operation.
Overview
The All-O-Matic 11 Lower Pivot Pin Retaining Clip is a jamb track hardware component for California Lift Gates. It is used in conjunction with lower pivot brackets, which are welded to the gate side rails after the gate is allowed to hang from the track rollers — a process that ensures a proper fit between the hardware and J-tracks.
Key Features
- Jamb Track Hardware designed specifically for California Lift Gate systems
- Works with lower pivot bracket assemblies secured to gate side rails
Installation Context
During installation, the gate must hang freely from the track rollers before the lower pivot brackets are welded in place. This ensures correct alignment and a good fit between the hardware and J-tracks. Once installed, J-tracks are adjusted parallel to the gate and fastened securely to the building structure.
The All-O-Matic 11 Lower Pivot Pin Retaining Clip is a reliable component for completing a properly fitted California Lift Gate jamb track assembly.
