AES ETRANS50-TX-KIT Transceiver Kit
SKU
ae-etrans50-tx-kit
The AES ETRANS50-TX-KIT is a bidirectional wireless access control transceiver kit that includes a transceiver, 4 E-TX fobs, and a 12 dBi antenna, operating at 433.39 MHz with a wide voltage range of 10–36V DC.
Overview
The AES ETRANS50-TX-KIT delivers bidirectional wireless access control for gate and door applications. This complete kit includes the ETRANS50 transceiver, 4 E-TX fobs, and a 12 dBi antenna. Its compact design offers exceptional range, and the SMA connector supports an optional long-range antenna connection.
Key Features
- Compact design with exceptional range
- SMA connector for optional long-range antenna connection
- Wide voltage range: 10–36V DC
- Exceptionally low current draw: standby 4.5 mA, active 30 mA
- Remote storage: 50 remotes, 4 x e-Loops, 4 x Keypads, 4 x Entry Buttons
- Relay: 1-amp contact rating, COM and N/O connections x 1 relay
- Multiple modes: Pulse, Latch and Hold
- Kit includes: Transceiver, 4 E-TX Fobs, and 12 dBi Antenna
Specifications
- Frequency: 433.39 MHz
- Voltage: 10–36V DC
- Standby current draw: 4.5 mA
- Active current draw: 30 mA
- Relay contact rating: 1-amp, COM and N/O x 1 relay
- Remote storage: 50 remotes, 4 x e-Loops, 4 x Keypads, 4 x Entry Buttons
- Antenna: 12 dBi (included)
The AES ETRANS50-TX-KIT is a ready-to-install kit designed for reliable wireless access control performance.
