Locinox MAG6000-9005 Maglock Surface Mount With Integrated H
The Locinox MAG6000-9005 is a surface-mounted electromagnetic lock featuring integrated handles, a weatherproof aluminum housing, and a minimal pulling force of 6000N (1300 lbs) — built for powered access control in exterior applications.
Overview
The Locinox MAG6000-9005 is a bolt-on electromagnetic lock designed for powered access control installations. Its aluminum powder-coated housing with integrated design handles delivers a clean, elegant appearance on access control gates. A two-layer protective coating is developed specifically for outdoor use, and the unit is 500-hour salt spray resistant with SGS Certification to ISO 9227. The raised edge on the magnet housing makes it impossible to insert a crowbar between the magnet and the armature plate, adding a critical layer of physical security.
Key Features
- Guaranteed holding force tested on every unit
- Minimal pulling force: 6000N (1300 lbs)
- 500-hour salt spray resistant — SGS Certified (ISO 9227)
- Special two-layer protective coating developed for outdoor use
- Weatherproof aluminum housing designed for exterior use
- Anti-residual magnetism kick-off system
- Raised edge on magnet housing prevents crowbar insertion between magnet and armature plate
- Fail open operation
- Fast and easy installation via 5 holes with Quick-Fix
Specifications
- Voltage: 12V / 24V DC
- Minimal Pulling Force: 6000N (1300 lbs)
- Current: 460mA at 12V or 230mA at 24V
- Housing: Powder-coated aluminum
- Color: Black
The Locinox MAG6000-9005 is the professional-grade choice for reliable, weather-resistant electromagnetic access control on gates.
