Locinox MAGMAG3000-9005 Surface Mounted Electromagnetic Lock
The Locinox MAGMAG3000-9005 is a surface mounted electromagnetic lock with a 660 lb minimum pulling force, weatherproof aluminum housing, and RAL 9005 black powder coat finish — built for exterior gate applications.
Overview
The Locinox MAGMAG3000-9005 is a screw-on, surface mounted electromagnetic lock without integrated handles. Its weatherproof aluminum housing features a special two-layer protective coating developed for outdoor use, and is rated to withstand 500 hours of salt spray per ISO 9227 (SGS Certified). The Quick-Fix mounting system uses just 5 holes — no welding required — for a fast, clean installation. Finished in RAL 9005 Black.
Key Features
- Minimum pulling force: 3000N (660 lbs) — holding force tested on every unit
- Anti-residual magnetism kick-off system
- Raised edge on magnet housing prevents crowbar insertion between magnet and armature plate
- Fast and easy fixing via 5 holes with Quick-Fix — no welding required
- Fail Open operation
- Special two-layer protective coating developed for outdoor use
- Weatherproof aluminum housing designed for exterior use
- 500h salt spray resistant — SGS Certified (ISO 9227)
- Rated for 500,000 cycles
Specifications
- Model: MAGMAG3000-9005
- Brand: Locinox
- Finish: RAL 9005 Black
- Material: Aluminum
- Mount: Surface
- Pulling Force: 3000N / 660 lbs (minimum)
- Voltage: 12V / 24V DC
- Current: 500 mA at 12V or 250 mA at 24V
- Height: 9-3/16 inches
- Length: 3.875 inches
- Width: 2-11/16 inches
- Standard: ISO 9227 (SGS Certified)
- Salt Spray Resistance: 500 hours
- Cycles: 500,000
- Warranty: 2 years
The Locinox MAGMAG3000-9005 delivers reliable, tested holding force with an installation-friendly design built to perform in demanding outdoor environments.
