Locinox MAG3000-9005 Magnetic Lock with Integrated Handles
The Locinox MAG3000-9005 is a surface-mounted electromagnetic lock featuring integrated handles, a minimal pulling force of 3000N (660 lbs), and a weatherproof aluminum housing built for exterior access control applications.
Overview
The Locinox MAG3000-9005 is a bolt-on electromagnetic lock engineered for powered access control on gates. Its aluminum powder-coated housing with integrated design handles delivers both security and a refined aesthetic. A patented Quick-Fix installation system requires drilling just 7 holes, eliminating the need for welding. A special two-layer protective coating ensures long-term performance in outdoor environments.
Key Features
- Guaranteed holding force tested on every unit
- Minimal pulling force: 3000N (660 lbs)
- 500-hour salt spray resistant — SGS Certified (ISO 9227)
- Special two-layer protective coating developed for outdoor use
- Weatherproof aluminum housing designed for exterior use
- Anti-residual magnetism kick-off system
- Raised edge on magnet housing prevents crowbar insertion between magnet and armature plate
- Fail open operation
- Fast installation via 5 Quick-Fix holes
- Integrated handles for a clean, finished appearance
Specifications
- Minimal Pulling Force: 3000N (660 lbs)
- Voltage: 12V / 24V DC
- Current: 500mA at 12V or 250mA at 24V
- Housing: Powder-coated aluminum
- Color: Black
- Salt Spray Rating: 500 hours (SGS Certified, ISO 9227)
The Locinox MAG3000-9005 is a professionally installed electromagnetic lock solution built to perform reliably in demanding outdoor access control environments.
