Lockey TB950 Magnum Gate Closer

Overview

The Lockey TB950 Magnum Gate Closer is a concealed, high-use pedestrian gate closer that combines the closer and hinge into a single tamper and vandal resistant system. It handles gates weighing between 50 and 250 lbs., works with both left and right hand gates, and features a restrictor to avoid over-opening. Speed adjustments are hidden from view, and the unit delivers two independent speed adjustments for closing and latching.

Key Features

• All-in-one closer and hinge system
• Self-closing with no hold-open
• Tamper and vandal resistant design
• Two speed adjustments: closing & latching
• Speed adjustments hidden from view
• Restrictor to avoid over-opening
• Works with left and right hand gates
• Max. opening angle: 90 degrees; 180 degrees capable with 180 Drive Plate*
• Mountable on chain link with TB950-LINX

Specifications

• Max. Gate Weight: 50–250 lbs.
• Max. Gate Width: 48"
• Max. Gate Height: 78"
• Max. Opening Angle: 90 degrees (180 degrees with 180 Drive Plate*)
• Min. Operating Temperature: -40°F
• Max. Operating Temperature: 122°F
• Gate Material Compatibility: Ornamental, Chain Link**
• Material: Steel
• Finish: Electro-galvanized

Compatibility

• Compatible with TB950-LINX for chain link gate installation

The Lockey TB950 is a professional-grade solution for demanding pedestrian gate applications requiring reliable, concealed self-closing performance.
