Maximum Controls 1400-HP-PRO Swing Gate Operator

Maximum Controls 1400-HP-PRO High Profile Commercial Swing Gate Operator

The Maximum Controls MAX MEGATRON 1400-HP-PRO is a high profile, high traffic, heavy duty commercial brushless DC swing gate operator capable of opening gates up to 1,400 lbs / 15 ft or 1,200 lbs / 20 ft. Its fast-speed direct drive system — with no chains, belts, or pulleys — opens a gate 90 degrees in 11.5 to 18 seconds based on gate weight and selectable speed control. The 1400-HP-PRO ships with AGM 7 amp hour battery backup enabling over 400 cycles in case of power failure. This operator is also compatible with existing installations and in most cases can be directly bolted onto concrete pads used by the most common gate operators in the industry.

With the introduction of the Matrix lll PRO Series control board, all Maximum Controls pad mount gate operators became solar ready. In solar mode (sleep mode) with a Solar Power Pack installed, the PRO series machines excel in commercial as well as residential applications. With the Solar Combiner, up to 4 Solar Power Packs with 200W solar panels can be wired together to form a single ended 24VDC supply source — a UL approved expandable feature only available from Maximum Controls.

Mechanical Specifications

• Dimensions: 18.3" W x 24.5" D x 21.3" H, 18.5" arm height
• Gate Capacity: 1,400 lbs / 15 ft or 1,200 lbs / 20 ft
• Gate Speed: 11-1/2 to 18 seconds for 90 degrees
• Gear Box: Heavy duty 900:1, Size 70
• Output Shaft: 3-1/4" diameter solid steel with cast iron clamping system
• Drive: Direct gear drive (no chains, belts, or pulleys)
• Mechanical and electrical manual gate release functions
• Corrosion protection gold zinc coating
• Continuous cycle at extreme temperature range with no overheating possibility
• Intelligent ramp-up and ramp-down gate speed control for smooth operation

Electrical Specifications

• Motor: Brushless DC motor equivalent to 1 HP AC motor
• Power Source: 115/230VAC (switchable) or 24VDC Solar
• Operational Voltage: 24VDC
• Battery Backup: 24VDC system with (2) 7-Ah batteries, up to 400 full cycles on backup
• Three modes of selectable battery backup functions
• Programmable gate speed controls with 16 selectable speeds
• Automatic gate position reset system
• Gate sync feature provides automatic gate movement synchronization
• Modular system design for ease of service
• Adaptive DSP control for advanced brushless DC motion control
• Real time performance analyzer and event log (OBD PORT and Black Box)
• Low voltage wiring capabilities for remote power up to 1,000 feet (no battery needed)
• Solar ready battery module with built-in advanced solar regulator
• Intelligent power management system with energy saver mode
• Built-in current limited 12VDC and 24VDC outputs
• Gold contact input connections and automobile grade connectors
• Selectable open timer 0 to 60 seconds with timer off option
• Operational Temperature Range: -4°F to 165°F (-20°C to +74°C) including battery performance without needing a heater
• Robust lightning protection up to 20KVolts and 10KAmps on all inputs and outputs (44 channels) including loop detector input connections
• Tunable 16 position safety obstruction sensor, auto adaptable to gate weight and size
• Dual motor overcurrent safety shut off for additional protection
• State machine design electronics with ultra-fast microprocessor
• On board three button station

Security Specifications

• High traffic intuitive loop management system for better security
• Advanced security features with built-in audible and remote alarms
• Magnetic lock control relay outputs with selectable delay times
• Tamper alert relay outputs triggered "on" if gate is forced open
• Audible alarm if gate is tampered with or ERD is triggered for higher security
• Gate partial open recorder
• Lockable cover with key lock release to prevent intruders and vandalism
• Gate disable feature — disables all inputs with exception of the fire department input for high security
• Built-in transaction buffer for high security
• Gate status outputs for gate monitoring
• Direct motor control of JOG OPEN/CLOSE for manually moving a gate in case of emergency

Warranty & Notes

• 5-Year Limited Manufacturer Warranty
• Additional Entrapment Prevention Devices REQUIRED

The Maximum Controls 1400-HP-PRO delivers true security with DSP motion control and high performance engineering built for demanding commercial gate applications.
