Maximum Controls MWRP Max Wireless Relay Pair
The Maximum Controls MWRP Max Wireless Relay Pair delivers long-range 900 MHz wireless control with a 2-channel relay transmitter and receiver capable of reaching up to one mile — making virtually any dry contact input/output device wireless.
Overview
The Maximum Controls MWRP Max Wireless Relay Pair is a long-range, 900 MHz, 2-channel relay transmitter and receiver system. It remotely activates, deactivates, and sends commands over distances of up to one mile. The two individual relays — 1 amp and 5 amp — function independently, allowing two different applications to run simultaneously. Almost any device with a dry contact input (switch ON or OFF) can be integrated.
Key Features
- 900 MHz long-range wireless technology
- 2-channel operation with independently functioning relays
- Up to one mile range
- 1 amp and 5 amp individual relays for two separate applications
- Compatible with virtually any dry contact input (switch ON or OFF) device
- Plug and play setup
- Locked transmitter/receiver pair
Compatible Applications with Maximum Controls Gate Operators
- Opening device control
- Gate tamper monitoring and controlling
- Monitor gate open and closed positions
- Turn on safety devices when the gate opens
- Interface tamper alarm with an existing alarm system to patented chain drop or swing gate push back
Specifications
- Frequency: 900 MHz
- Channels: 2
- Range: Up to one mile
- Relay 1: 1 amp
- Relay 2: 5 amp
- Shipping Weight: 3 lbs.
- Manufacturer Part Number: MAX-WIRELESS-RELAY-PAIR
The Maximum Controls MWRP is a reliable solution for adding wireless capability to any compatible dry contact device in gate access control applications.
