Maximum Controls MEGA-2200-PRO Swing Gate Operator
The Maximum Controls MEGA-2200-PRO is a heavy-duty commercial brushless DC swing gate operator rated for gates up to 2,500 lbs./15 ft. or 1,800 lbs./20 ft., featuring direct gear drive and a 24VDC battery backup system capable of over 400 full cycles.
Maximum Controls MEGA-2200-PRO Heavy Duty Commercial Swing Gate Operator
The Maximum Controls MEGA-2200-PRO is a high-traffic, heavy-duty commercial swing gate operator powered by a continuous duty brushless DC motor equivalent to a 1/2 HP AC motor. Operating at 24VDC, it handles gates up to 2,500 lbs. at 15 ft. or 1,800 lbs. at 20 ft. with a direct gear drive system — no chains, belts, or pulleys. Gate opening speed ranges from 11-1/2 to 18 seconds based on gate weight and selectable speed control. The unit ships with a 24VDC AGM battery backup system with two 7 Ah batteries, delivering over 400 full cycles during a power failure. A 5-year limited manufacturer warranty is included. Must be installed by a professional gate installer.
Key Features
- Direct gear drive — no chains, belts, or pulleys
- Continuous duty brushless DC motor equivalent to 1/2 HP AC motor
- Intelligent ramp-up and ramp-down gate speed control for smooth operation
- 16 selectable programmable gate speed settings
- Three modes of selectable battery backup functions
- Matrix-III board — solar ready with built-in advanced solar regulator
- Solar Combiner supports up to 4 Solar Power Packs with 200W solar panels wired as a single-ended 24VDC supply source (UL approved)
- Adaptive DSP control for advanced brushless DC motion control
- Tunable 16-position safety obstruction sensor, auto-adaptable to gate weight and size
- Dual motor overcurrent safety shut-off
- Dynamic magnetic brake system stops gate immediately
- Vehicle hit protection technology
- Pinch arm protection design
- Robust lightning protection up to 20KVolts and 10KAmps on all inputs and outputs (44 channels), including loop detector input connections
- Real-time performance analyzer and event log (OBD PORT and Black Box)
- Low voltage wiring capabilities for remote power up to 1,000 feet (no battery needed)
- Selectable open timer 0 to 60 seconds with timer off option
- Switchable 115/230V AC selection
- Built-in current limited 12VDC and 24VDC outputs
- Gold contact input connections and automobile-grade connectors
- Hall Effect sensing
- High-traffic intuitive loop management system
- Tamper alert relay outputs triggered if gate is forced open
- Audible alarm if gate is tampered with or ERD is triggered
- Magnetic lock control relay outputs with selectable delay times
- Lockable cover with key lock release
- Gate disable feature — disables all inputs except fire department input
- Advanced anti-tailgate features
- Built-in transaction buffer
- Gate status outputs for gate monitoring
- Direct motor control of jog OPEN/CLOSE for emergency manual gate movement
- Automatic gate position reset system
- On-board three-button station
- State machine design electronics with ultra-fast microprocessor
- Modular system design for ease of service
- Intelligent power management system with energy saver mode
- Compatible with existing installations — in most cases can be directly bolted onto concrete pads used by most common gate operators in the industry
- UL 325/991 compliant Class I, II, III, and IV. CSA approved
- Additional entrapment prevention devices required
Specifications
- Operational Voltage: 24VDC
- AC Input: Switchable 115/230V AC
- Gate Capacity: 2,500 lbs./15 ft. or 1,800 lbs./20 ft.
- Gate Opening Speed: 11-1/2 to 18 seconds (based on gate weight and selectable speed control)
- Motor: Continuous duty brushless DC, equivalent to 1/2 HP AC motor
- Battery Backup: 24VDC with two 7 Ah AGM batteries — over 400 full cycles
- Dimensions: 16.81" W x 24.5" D x 29.92" H; arm height 26.61"
- Gearbox: Heavy duty 900:1 Size 80
- Output Shaft: 3-1/4" diameter solid steel with cast iron clamping system
- Operational Temperature Range: -4°F to 165°F (-20°C to +74°C) including battery performance
- Lightning Protection: Up to 20KVolts and 10KAmps on all inputs and outputs (44 channels)
- Corrosion Protection: Gold zinc coating
- Warranty: 5-year limited manufacturer warranty
- Manufacturer Part Number: MAX-MEGATRON-2200-PRO
Compatibility
The MEGA-2200-PRO is compatible with existing installations and in most cases can be directly bolted onto concrete pads used by the most common gate operators in the industry. The Matrix-III board makes all Maximum Controls pad mount gate operators solar ready; with a Solar Combiner, up to 4 Solar Power Packs with 200W solar panels can be wired together as a single-ended 24VDC supply source.
The Maximum Controls MEGA-2200-PRO delivers industrial-grade performance, advanced security, and flexible solar capabilities for demanding commercial swing gate applications — and must be installed by a professional gate installer.
