Linear DNR00105 MGR-2 2-Channel Gate Receiver
The Linear MGR-2 (DNR00105) is a 2-Channel Gate Receiver using the MegaCode radio format with over 1,000,000 possible code combinations and storage for up to 40 transmitters.
Overview
The Linear MGR-2 is a 2-Channel Gate Receiver designed for use with automatic gate operators or systems where a remote antenna is needed. It offers flexible operation: run two gates independently, control one gate alongside an obstacle sensor, or dedicate channel one to opening and channel two to closing a single gate. The MGR-2 operates on the MegaCode radio format, delivering over 1,000,000 possible code combinations for secure access control.
Key Features
- Two Form "A" (normally open) relays rated at 30 Volts AC/DC up to 5 Amps
- Supplied with whip antenna, three feet of coaxial cable, and bulkhead connector
- Stores up to 40 MegaCode transmitters
- MegaCode format with 1,000,000+ code combinations
- RF frequency: 318 MHz
Specifications
- Power: 12 – 30 VAC or 10.5 – 30 VDC
- RF Frequency: 318 MHz
- Codes: 1,000,000+ (MegaCode format)
- Memory: Up to 40 MegaCode transmitters
- Relay Rating: 30 Volts AC/DC, up to 5 Amps (Form "A", normally open)
- Dimensions: 3.625" W x 5.25" H x 1.5" D
The Linear MGR-2 (DNR00105) delivers reliable MegaCode reception and flexible two-channel control for professional gate operator installations.
