Linear DNR00104 1-Channel Gate Receiver
SKU
ln-dnr00104
The Linear MGR (DNR00104) is a 1-Channel Gate Receiver using the MegaCode radio format with over 1,000,000 possible code combinations and storage for up to 40 transmitters.
Overview
The Linear MGR is a 1-Channel Gate Receiver designed for use with automatic gate operators or systems where a remote antenna is needed. It operates on the MegaCode radio format, offering over 1,000,000 possible code combinations for reliable access security.
Key Features
- Single Form "A" (normally open) relay rated at 30 Volts AC/DC up to 5 Amps
- Supplied with whip antenna, three feet of coaxial cable, and bulkhead connector
- Stores up to 40 MegaCode transmitters
- MegaCode format with 1,000,000+ possible code combinations
- RF frequency: 318 MHz
Specifications
- Power: 12 – 30 VAC or 10.5 – 30 VDC
- RF Frequency: 318 MHz
- Relay: Single Form "A" (normally open), 30V AC/DC, up to 5 Amps
- Transmitter Memory: Up to 40 MegaCode transmitters
- Codes: 1,000,000+ (MegaCode format)
- Dimensions: 3.625" W x 5.25" H x 1.5" D
The Linear MGR DNR00104 delivers dependable MegaCode reception for automatic gate operator installations requiring a remote antenna solution.
